Proposed Two Family Project for Anthony Faiazza

110 High St., View Royal

South West View architectural rendering
South West View architectural rendering
Aerial view satellite map with property line and existing house overlays
Aerial view satellite map with property line and existing house overlays

Site Area - 20,909sf

Front Unit:

  • main floor - 1125sf
  • upper floor - 462sf

Rear Unit:

  • main floor - 1149sf
  • upper floor - 398sf

Garage - 656sf
