Attachment 7: Detailed store layout and entrance elevation – Applicant – March 18, 2019

Architectural Floor Plan and Storefront Elevation

Storefront Elevation

The elevation drawing shows the exterior storefront design featuring:

• A central entrance door.
• Two large display windows flanking the door.
• A designated rectangular area for SIGNAGE above the windows and door.
• External light fixtures on both sides of the storefront.

Floor Plan Details

General Specifications:

• Total Area: 871 sq ft
• Overall Dimensions: 17'-6" (width) x 54'-0" (length)

Public and Sales Area:

• Public Area: Entrance section featuring "EXPANDABLE SECURITY GATES" and an "ATM". Exterior "CONCRETE BOLLARDS" are positioned in front of the entrance.
• Sales Area: The main retail space is 16'-4 1/2" wide.
  • Equipped with three POS (Point of Sale) stations.
  • Features four SAMPLE CASE units.
  • Wall displays including three sections for CANNABIS, a PIPE DISPLAY CASE, and an ACCESSORY SHELF.
  • Key internal dimensions: 29'-5 1/2", 28'-5 1/4", 8'-10", 7'-2 1/2", 5'-2", and 4'.

Back of House Area:

• Storage: A room measuring 9'-0 1/2" x 7'-6" which includes a DESK.
• Staff Area: A room measuring 9'-0 1/2" x 8'-7" equipped with a sink.
• Restroom: Located within the staff area, with dimensions of approximately 6'-8 1/2" x 7'-7 1/2".

Security Features:

• Security Cameras: Locations are indicated throughout the public, sales, and staff areas.
• Alarm Panel: Positioned near the public area entrance.

Document Metadata

• Date: 2019-03-18
• Sheet: A#
