Attachment 10: Referral comments – CROAD Water Supply and Engineering

RE: PROPOSED REZONING OF LOT A, SECTION 2, ESQUIMALT DISTRICT, PLAN VIP61203 (1495 ADMIRALS ROAD)

Thank you for your rezoning referral received February 21, 2020, which requests that we examine the above mentioned proposal with regard to the water supply regulations and policies of the Capital Regional District (CRD) Integrated Water Services as established for the Juan de Fuca Water Distribution Commission.

Community piped water can be supplied to this proposed development provided that the Owner(s) is prepared to pay the necessary costs and fees as authorized under CRD Bylaw No. 4190, for the supply and installation of a water distribution system capable of meeting all domestic and fire flow requirements, designed in accordance with CRD Specifications and Standard Drawings.

The subject property is presently serviced with water by a 150mm (6") water service located at the property frontage on Admirals Road. The Owner(s) shall pay all costs to abandon, relocate or upgrade this service if required, for this development.

The hydraulic computer model maintained by the CRD shows that a fire flow of 15,000 L/min (3,300 Igpm) with at least 138 kPa (20 psi) residual pressure is presently available to this property in the water main adjacent to the fire hydrant (VRFD106) located at the intersection of Admirals Road and Aldersmith Place.

Please note that the fire flow stated above does not account for the maximum allowable velocity in the water mains under fire flow conditions permitted by the CRD. Depending on the fire flow requirements of the development, upgrading of the existing water distribution system may be required.

In stating the fire flow available, the CRD expresses no opinion as to the adequacy of the stated fire flow to provide fire protection and if applicable, recommends that the Owner(s) take the appropriate steps to confirm the available fire flow by means of a field hydrant flow test (if required the hydrant flow test will be carried out by CRD staff at the Owner(s) expense). Results of the field hydrant flow test may have to be adjusted to reflect a maximum day demand scenario.

The Owner's Engineer will be required to calculate the fire flow requirements to Fire Underwriters Survey (FUS) standards for the development and confirm in writing to both the CRD and the Town of View Royal that the available flow from the CRD system is sufficient. It is recommended the Owner's Engineer contact the Town of View Royal to discuss hydrant location and orientation.

If an increase in the level of fire protection is required to meet CRD Engineering Specifications and Standard Drawings, FUS or to meet the requirements of the Town of View Royal, the Owner(s) would be responsible for all costs associated with designing and upgrading the distribution system to the extent necessary to provide the required flows.

It is assumed that the wastewater generated from this development will eventually be discharged into the regional sewer system for eventual treatment and disposal at the CRD McLoughlin Point Wastewater Treatment Plant. Please be reminded that the Town of View Royal has an allocated capacity in the regional conveyance and treatment system as defined in Bylaw 2312, “Liquid Waste Management Core Area and Western Communities Service Establishment Bylaw No. 1, 1995”. The CRD will require the Town of View Royal to review and confirm that the additional wastewater flows generated from this proposed development does not exceed View Royal's total allocated capacity in the regional system.

This letter is for the purpose of providing you with information regarding the services available from the CRD, and should not be construed as either approval or rejection of the proposed rezoning by the CRD.

CRD comments related to the Regional Water Supply (RWS) Service will be provided in a separate response.

These conditions are valid for 180 days from date of writing. However, if at any time there is a change in legislation, regulations and CRD Bylaw No. 4190, which would cause any of the above conditions to be non-conforming, then the CRD reserves the right to revise any or all of the conditions accordingly, at any time during the 180 day period.

Yours truly,

Shayne Irg, P.Eng. Acting Manager, Water Distribution Engineering and Planning Infrastructure Engineering Integrated Water Services

cc:

• Ian Jesney, Senior Manager, Infrastructure Engineering
• Amrit Sandhar, Senior Project Technologist, Water Supply Engineering and Planning
• Christine Condron, Real Estate Services, Corporate Services
• Lt. Rob Marshall, Fire Prevention Officer, View Royal Fire Rescue
