Council Meeting/Documents/Attachment 5: Site Plan of Proposed Subdivision (A-101)
Appendix

Attachment 5: Site Plan of Proposed Subdivision (A-101)

May 21, 2013Page 421 section

Detailed site plan showing building footprints, parking stalls, and property boundaries.

1 CALL TO ORDER
Address: 1649 Lloyd PlaceTotal parking provided: 25 stallsLot Area: 4300 m2

Site Plan of Proposed Subdivision of Lot 2, Section 98, Esquimalt District, Plan VIP85318 & Part of Strata Lot E, Section 98, Esquimalt District, Strata Plan VIS6651

Surveyor Information

February 20, 2013
9062 TH-SITE_8.DWG
File: 9062-36A
POWELL & ASSOCIATES
B C Land Surveyors
250-2950 Douglas Street
Victoria, BC V8T 4N4
phone (250) 382-8855

General Notes

  • All distances are shown in metres.
  • Elevations are geodetic
  • Contour interval = 0.50 metres

Legend

  • ● denotes stake
  • + denotes existing exposure
  • □ denotes probable platform
  • Location of Archaeological features provided by Millenia Research and have not been field verified by Powell & Associates
Detailed site plan map showing property boundaries, topography contours, existing trees, archaeological features, and proposed subdivision into lots including Block 'A', Block 'B', and Block 'C' (house), along with Lloyd Place Common Property Road and adjacent Plan 24900, Plan VIP85318, and Plan VIP83832.
Detailed site plan map showing property boundaries, topography contours, existing trees, archaeological features, and proposed subdivision into lots including Block 'A', Block 'B', and Block 'C' (house), along with Lloyd Place Common Property Road and adjacent Plan 24900, Plan VIP85318, and Plan VIP83832.

Design Data

  • LEGAL: PLAN OF PROPOSED BARE LAND STRATA SUBDIVISION OF LOTS '1', SECTION 98, ESQUIMALT DISTRICT, PLAN 19813 AND PART OF LOT 'B' SECTION 98, ESQUIMALT DISTRICT PLAN 19807
  • CIVIC ADDRESS: 1649 LLOYD PLACE, VICTORIA, B. C.
  • ZONING: R-2
  • SITE AREA: 46 284.176 SQ. FT. (4 299.8 SQ. M.)

PROPOSED GROSS FLOOR AREA:

BLOCK 'A' 'B' 'C'
BASEMENT 1 737.00 2 454.00
MAIN FLOOR 2 833.00 3 777.00 818.00 (EXCLUDING GARAGES)
2ND FLOOR 3 363.00 4 362.00 843.00
SUB TOTAL 7 933.00 10 593.00 1 661.00
TOTAL 20 092.01 SQ. FT. (1 866.54 SQ. M.)
  • F.S.R. = 0.434
  • TOTAL NO. OF UNITS = 8 TOWNHOUSES + ONE HOUSE
  • SITE COVERAGE: (4 722 + 3 441 + 1 028) 9 191 SQ. FT. (853.84 SQ. M.) 19.85 %
  • OPEN SITE AREA: 37 475.33 SQ. FT. (3 481.42 SQ. M.) 79.42 %
  • BUILDING HEIGHT: 8.058 M (0.558 M VARIANCE REQUESTED)
  • PARKING PROVIDED: 25 STALLS (10 UNITS (2 X 10 = 20 CARS) + 5 VISITOR PARKINGS)

Revision History

DATE DESCRIPTION
MAR. 31, 08 DP APPLICATION
JUNE 3, 09 DP APPLICATION
OCT. 22, 09 DP APPLICATION
OCT. 26, 10 DP APPLICATION
JUNE 15, 12 VISITOR PARKING
OCT. 16, 12 RETAINERS FOR DP
FEB. 5, 13 NEW BLOCKS

Issuance Information

DATE DESCRIPTION
MAR. 3, 10 DP APPLICATION

Project Information

  • PROPOSED RESIDENTIAL DEVELOPMENT
  • 1649 LLOYD PLACE, VICTORIA, B.C.
  • FOR: KANG & GILL DEVELOPMENTS LTD.
  • SITE PLAN, DESIGN DATA
  • SCALE: AS NOTED
  • DATE: DEC. 19, 2007
  • DRAWN: PAV
  • PRN: ADG
  • PROJECT NO. 07:11
  • DRAWING NO. A-101

Site Plan Legend

  • [00,000 M] FINISHED GRADE
  • 00,000 M EXISTING GRADE
Page 42
Extracted from: 2013 05 21 Council Agenda
