Attachment 8: Floor Plans Block 'B' (A-202)

May 21, 2013Page 451 section

Architectural drawings showing the basement and main floor plans for the units in Block B.

1 CALL TO ORDER
Main floor area: 3,777 sq. ft.

PROPOSED RESIDENTIAL DEVELOPMENT ON 1045 LLOYD PLACE, VICTORIA, B.C.

FLOOR PLANS BLOCK 'B'

Architectural drawing sheet A-202 showing the Main Floor Plan and Basement Plan for Block B of a residential development at 1045 Lloyd Place.
Architectural drawing sheet A-202 showing the Main Floor Plan and Basement Plan for Block B of a residential development at 1045 Lloyd Place.

Project Information

  • Project No.: 07:11
  • Date: DEC. 10, 2007
  • Architect: MISRA ARCHITECT LTD.
  • For: KAHN & GILL DEVELOPMENTS LTD.

Revisions

Date Description
MAR. 10, '08 DP APPLICATION
SEPT. 23, '08 BLDG. PERM.
OCT. 02, '08 DP APPLICATION
MAR. 5, '13 NEW BLOCKS
JULY 13, '13 DP APPLICATION

Main Floor Plan

  • Scale: 1/8" = 1'-0"
  • Floor Area: 3 777.00 SQ. FT.

Basement Plan

  • Scale: 1/8" = 1'-0"
  • Building Area: 4 722.00 SQ. FT.
  • Floor Area: 2 454.00 SQ. FT. (EXCLUDING GARAGES)

Legend

  • Finished Grade
  • Existing Grade
