Attachment 10: Plans & Elevations Block 'C' (A-204)

Plans & Elevations Block 'C'

Project Information

Floor Plans

1. Main Floor Plan

• Scale: 1/8" = 1'-0"
• Building Area: 1,028.00 sq. ft.
• Floor Area (Excluding Garage): 776.80 sq. ft.
• Rooms/Features: Kitchen, Family Room, Living/Dining, Open to Above, Garage, Concrete Retaining Wall.

2. Second Floor Plan

• Scale: 1/8" = 1'-0"
• Floor Area: 895.00 sq. ft.
• Rooms/Features: M. Bedroom, Bedroom, Balcony, Open to Below.

3. Roof Plan

• Scale: 1/8" = 1'-0"

Elevations and Section

4. West Elevation

• Scale: 1/8" = 1'-0"
• Grade Elevations: 30.90 m, 32.55 m, 32.20 m, 31.10 m.

5. South Elevation

• Scale: 1/8" = 1'-0"
• Grade Elevations: 31.50 m, 32.20 m, 32.50 m, 31.20 m.

6. East Elevation

• Scale: 1/8" = 1'-0"
• Grade Elevations: 31.60 m, 31.20 m, 31.30 m, 32.50 m.

7. North Elevation

• Scale: 1/8" = 1'-0"
• Grade Elevations: 31.90 m, 33.10 m, 33.50 m, 32.05 m.

8. Section

• Scale: 1/8" = 1'-0"
• Average Existing Grade: 32.15 m
• Maximum Height (from MFE): 6.353 m (20'-10 1/8")

Materials and Specifications

The elevations indicate the following building materials:

• Asphalt shingles
• Concrete siding hardy panels
• Metal railing
• 10" fascia board
• 8" wood trim
• 4" wood trim
• 2" wood trim

Revision History

Legend

• Finished Grade: Marked with a crosshair symbol (+)
• Existing Grade: Marked with a plus symbol with a small circle (⨁)

Notes

• These plans are copyright drawings and shall not be reproduced in part or in whole without written permission and must be returned to the architect upon demand.
• Drawings must be read in conjunction with all relevant structural, mechanical, and electrical drawings. Any discrepancies must be reported to the architect before construction begins.
• All construction must comply with local building codes and bylaws.
