Attachment 13: Elevations Block 'B' (A-302)

PROPOSED RESIDENTIAL DEVELOPMENT ON 1049 LLOYD PLACE, VICTORIA, B.C.

Architectural drawing showing West, South, North, and East elevations for Block 'B' of a proposed residential development at 1049 Lloyd Place.

Revisions

Date	Description
MAR 11, 08	DP APPLICATION
SEPT. 21, 09	REVISED ROOM
OCT. 02, 09	DP APPLICATION
MAR 8, 10	NEW FLOORS

Issued For

Date	Description
JULY 10, 10	DP APPLICATION
MAR 8, 10	DP APPLICATION

Elevations Block 'B'

1 WEST ELEVATION

Scale: 1/8" : 1'-0"
Reference Levels: 31.757 M, 29.014 M, 26.274 M

2 SOUTH ELEVATION

Scale: 1/8" : 1'-0"
Reference Levels: 31.757 M, 29.014 M

3 NORTH ELEVATION

Scale: 1/8" : 1'-0"
Reference Levels: 31.757 M, 29.014 M, 26.270 M

4 EAST ELEVATION

Scale: 1/8" : 1'-0"
Reference Levels: 31.757 M, 29.014 M, 26.270 M

Legend

FINISHED GRADE: (Solid line)
EXISTING GRADE: (Dashed line)

Project Information

FOR: KANG & GILL DEVELOPMENTS LTD.
SCALE: AS NOTED
DATE: DEC. 10, 2007
DRAWN: PKM
PROJECT NO.: 07:11
DRAWING NO.: A-302

Notes

NOTE: This is a copyright drawing and shall not be reproduced or resold without written permission and must be returned to Misra Architect Ltd. upon request. The contractor shall check and verify all dimensions and notify the architect of any discrepancy. This drawing shall not be used for construction purposes until so approved.
