Color rendering and material palette for the building exteriors.

1 CALL TO ORDER
Materials include Hardie planks, Hardie panels, and stone facing

Color Scheme - Part of East Elevation

Architectural elevation drawing showing building materials and color scheme for a residential project at 1649 Lloyd Place.
Architectural elevation drawing showing building materials and color scheme for a residential project at 1649 Lloyd Place.

Material Specifications

  • Asphalt Shingles
  • Stained Cedar Shakes
  • Hardie Planks GP 8683 W
  • Hardie Panels GP 8695 D
  • 1"x6" Wood Trim GP 8690 W
  • Cultured Stone Facing

Project Information

  • Project: Proposed Residential Development on 1649 Lloyd Place, Victoria, B.C.
  • Client: Kang & Gill Developments Ltd.
  • Architect: Misra Architect Ltd., 2225 Poter Road, Victoria, BC V8N 1V5
  • Project No.: 07:11
  • Drawing No.: C-1
  • Drawing Title: Part of East Elevation
  • Scale: As Noted (Elevation scale: N.T.S.)
  • Date: Jan. 9, 2013
  • Drawn By: PKM
