SIGN DIMENSIONS

November 5, 2013Page 131 section

Technical drawings and elevation views detailing the structural design and size of the proposed temporary signs.

1 CALL TO ORDER
Elevation 1:505' heightOctober 3, 2013

SIGN DIMENSIONS

Hand-drawn technical sketch of a sign showing elevation and section views with dimensions and material notes.
Hand-drawn technical sketch of a sign showing elevation and section views with dimensions and material notes.

ELEVATION: 1:50

  • Dimensions: 6' width; 5' height (to top of frame).
  • Notes:
    • FRAME STAIN TO MATCH PROJECT COLOUR SCHEME.
    • SIGN (center panel).
    • CLIPS PAINT BLACK.

SECTION: 1:10

  • Dimension: 40 (1 ½")
  • Notes:
    • SIGN PANEL
    • CLIPS / BLACK
    • BLOCKING.
    • 2"x8" RAILS.
    • 6"x8" POSTS.

SIGN DETAIL

  • Graphic: Large number "4" followed by "MILE".
  • Date: OCT 3 / 2013.
