Attachment 6: August 28, 2019 Conceptual Servicing/Access Plan prepared by Islander Engineering

7 ERSKINE LANE CONCEPTUAL SERVICING / ACCESS PLAN

DP / REZONING APPLICATION

FOR DISCUSSION PURPOSES ONLY

DATE: AUGUST 28, 2019

CIVIC ADDRESS: 7 ERSKINE LANE LOT A TOWN OF VIEW ROYAL, PLAN VIP57062

SITE PLAN NOTES

Servicing and Utilities:

• WATERMAIN UPGRADE LIKELY REQUIRED TO ACCOMMODATE MAXIMUM ALLOWABLE FIRE FLOW VELOCITY.
• NEW WATER SERVICE C/W DOMESTIC METER AND DOMESTIC / FIRE BACKFLOW PREVENTOR.
• PROPOSED GAS SERVICE.
• NEW ROYAL CREWS TO INSTALL NEW DRAIN SERVICE.
• NEW ROYAL CREWS TO INSTALL NEW SANITARY SERVICE.
• EXTENT OF UNDERGROUND PARKING GARAGE.
• REMOVAL OF EXISTING PRIVATE HYDRO POLES TO BE COORDINATED.
• STORMWATER TREATMENT WITHIN PLANTED AREAS.
• STORMWATER DETENTION BENEATH PARKING LOT.
• EXISTING DITCH TO BE DECOMMISSIONED. DRAINAGE TO BE DIRECTED TO EX. CATCH BASINS.
• EXISTING STORMWATER DISCHARGE TO CRAIGFLOWER CREEK.

Land and Access:

• POSSIBLE FUTURE SRW ON 9 ERSKINE LANE FOR FUTURE SIDEWALK.
• POSSIBLE FUTURE SRW ON 10 ERSKINE LANE FOR PROPOSED SIDEWALK.
• FIRE TRUCK STAGING LOCATION.
• ACCESS TO STAGING AREA NOT MORE THAN 8% IN GRADE.
• TURNING RADIUS AT CENTERLINE IS 12m (TYP.)

Project Information:

• IEL PROJECT: 2046
• ISSUED: AUGUST 28 2019
• DRAWN BY: JL
• CHECKED BY: JZB
