Proposed Entrance Gates - Sheet Two of Two (Attachment 6)

June 4, 2013Page 161 section

Plan and elevation drawings for the proposed gates at 333A Stewart Avenue.

1 CALL TO ORDER
Date: March 28, 2013Design: stone columns with metal gates

Proposed Entrance Gates - 333a Stewart Avenue

Date: March 28, 2013

Site plan and front elevation architectural drawings for proposed entrance gates at 333a Stewart Avenue, showing the driveway layout, garage, and gate specifications.
Site plan and front elevation architectural drawings for proposed entrance gates at 333a Stewart Avenue, showing the driveway layout, garage, and gate specifications.

Plan & Elevation of Gates

Scale: 1/4" = 1'-0"

Design Specifications:

  • Cast concrete post caps
  • Metal gates
  • Stone facing to match house

Elevation Dimensions:

  • Horizontal: 0.76m, 1.12m, 0.76m, 5.21m, 2.74m
  • Vertical: 1.22m, 1.52m
Page 16
