Proposed Entrance Gates - Sheet Two of Two (Attachment 6) - 335 Stewart Avenue

June 4, 2013Page 261 section

Plan and elevation drawings for the proposed gates at 335 Stewart Avenue.

1 CALL TO ORDER
Date: April 9, 2013Address: 335 Stewart Avenue

Proposed Entrance Gates - 335 Stewart Avenue

Plan and elevation architectural drawings for proposed entrance gates at 335 Stewart Avenue, illustrating site layout, gate mechanics, and material specifications.
Plan and elevation architectural drawings for proposed entrance gates at 335 Stewart Avenue, illustrating site layout, gate mechanics, and material specifications.

Plan & Elevation of Gates

Scale: 1/4" = 1'-0"

Date April 9, 2013
Sheet Two of Two
Designer Bruce Wilkin Design (designers + builders)

Drawing Annotations and Specifications:

  • Stewart Avenue
  • Existing Driveway
  • Sliding Metal Gate
  • Stone Faced Wall
  • Cast Concrete Post Caps
  • Stone Facing
  • Property Line

Dimensions:

  • 1.42m
  • 3.65m
  • 5.06m
Page 26
