Council Meeting/Documents/Attachment 17. Plan A2.2 - Underground Parking
Appendix

Attachment 17. Plan A2.2 - Underground Parking

December 10, 2013Page 311 section

Floor plan for the underground parking level.

1 CALL TO ORDER
425 Total Underground Stalls60 Secured Residential Stalls

EAGLE CREEK VILLAGE

UNDERGROUND PARKING

Architectural drawing of the underground parking level for Eagle Creek Village showing the layout of parking stalls, visitor parking, residential parking, and service areas.
Architectural drawing of the underground parking level for Eagle Creek Village showing the layout of parking stalls, visitor parking, residential parking, and service areas.

Project Information

  • Location: Watkiss Way & Helmcken Road, View Royal, BC
  • Date: 25 Jan 2013
  • Drawing Number: A2.2
  • Scale: 1:500 (As indicated)

Parking Statistics

  • Total Parking: 425 Stalls
  • Parking: 335 Stalls
  • Visitor Parking Stalls (Indicated as Shaded): 30 Stalls
  • Residential Parking: 60 Stalls

Plan Details

  • Ramp Up to Surface
  • Point of Secured Parking
  • Line of Building Above

Underground Parking Legend

  1. SERVICE ROOM / STORAGE
  2. GLASS / SIGNAGE
  3. BICYCLE ROOM / STORAGE
  4. MECHANICAL EXHAUST WELL --- BUILDING ABOVE
Page 31
Extracted from: 2013 12 10 Council Agenda
