Attachment 19. Plan A2.4 - Site Sections

December 10, 2013Page 331 section

Cross-sectional drawings of the site showing building elevations and grade changes.

1 CALL TO ORDER

EAGLE CREEK VILLAGE - SITE SECTIONS

Architectural site sections for Eagle Creek Village showing building elevations, parking structures, and access routes from Watkiss Way and Helmcken Road.
Architectural site sections for Eagle Creek Village showing building elevations, parking structures, and access routes from Watkiss Way and Helmcken Road.

1 SITE SECTION 1

Scale: 1:400

Features and labels (west to east):

  • Site Access from Watkiss Way
  • Building 5
  • Building 3 & 4
    • Grocery Store
    • Underground Parking
  • Building 6
  • Pedestrian Mews
  • Building 7
    • Retail (ground level)
    • Office (four levels)
  • Property Line
  • Helmcken Road

2 SITE SECTION 2

Scale: 1:400

Features and labels (west to east):

  • Retail
  • Building 5
  • Site Access from Watkiss Way
  • Building 3 & 4
  • Building 2
  • Surface Parking
  • Underground Parking
  • Retail
  • Building 1
  • Property Line
  • Helmcken Road

Project Information

  • Project: Eagle Creek Village
  • Location: Watkiss Way & Helmcken Road, View Royal, BC
  • Sheet Title: Site Sections
  • Sheet Number: A2.4
  • Date: 25 Jan 2023
  • Scale: 1:400
