Attachment 20. Plan A2.5 - Site Sections

December 10, 2013Page 341 section

Additional cross-sectional drawings through Buildings 4, 6, and 7.

1 CALL TO ORDER

EAGLE CREEK VILLAGE

SITE SECTIONS

Project Details

  • Location: Watkiss Way & Helmcken Road, View Royal, BC
  • Date: 25 Jan. 2013
  • Drawing Number: A2.5
  • Scale: 1:400
Architectural site sections for Eagle Creek Village, showing building elevations, floor uses, parking structures, and site topography.
Architectural site sections for Eagle Creek Village, showing building elevations, floor uses, parking structures, and site topography.

SITE SECTION 3

  • Watkiss Way: Adjacent street level.
  • Building 6: Grocery Store with Underground Parking.
  • Site Features: Ramp down to parking and Surface Parking area.
  • Building 4: Retail on the ground level with three levels of Residential units above.
  • Adjacent Property: Townhouse located beyond the property line.

SITE SECTION 4

  • Watkiss Way: Adjacent street level.
  • Building 7: Retail on the ground level with four levels of Office space above and Underground Parking.
  • Building 5 Area: Designated for Surface Parking.
  • Site Access: Route from Helmcken Road.
  • Building 3 & 4 Area
  • Building 2: Retail space with U/G (Underground) Parking.
  • Adjacent Property: Townhouse located beyond the property line.
Page 34
