Attachment 23. Plan A3.2 - Building 1 & 8 Elevation & Sections
December 10, 2013Page 371 section
Architectural elevations and sections for Buildings 1 and 8.
EAGLE CREEK VILLAGE
BUILDING 1 & 8 - ELEVATION & SECTIONS
Watkiss Way & Helmcken Road, View Royal, BC 03 July 2013
2 ELEVATION - BUILDING 1 & 8 SOUTH
Scale: 1:200
3 SECTION - BUILDING 1
Scale: 1:200
ELEVATION LEGEND
| Key | Description |
|---|---|
| 01 | DOUBLE GLAZED ALUMINUM STOREFRONT |
| 02 | DOUBLE GLAZED ALUMINUM WINDOW |
| 03 | CEMENTITIOUS BOARD & BATTEN SIDING |
| 04 | CEMENTITIOUS PANELS |
| 05 | CEMENTITIOUS HORIZONTAL PLANK SIDING |
| 06 | H.S.S. BRACES |
| 07 | ARCHITECTURAL CONCRETE |
| 08 | CULTURED STONE |
| 09 | ALUMINUM RAILING |
| 10 | ALUMINUM RAILING WITH CEMENTITIOUS PANELS |
| 11 | SHAKE STYLE ASPHALT SHINGLES |
| 12 | PAINTED DECORATIVE METAL SCREEN |
| 13 | SIGNAGE |
| 14 | DOUBLE GLAZED WINDOW WALL WITH SPANDREL PANELS |
| 15 | O/H DOOR W/ GLASS PANEL |
| 16 | OUTLINE OF ROOF TOP UNIT SCREEN |
| 17 | GLAZED OVERHEAD DOOR |
| 21 | LOCATION OF MID-MOUNTING POINT OF SIGNAGE AREA NOT TO EXCEED 20 SQ.FT. |
| 22 | LOCATION OF MID-MOUNTING POINT OF SIGNAGE AREA NOT TO EXCEED 40 SQ.FT. |
| 23 | LOCATION OF MID-MOUNTING POINT OF SIGNAGE AREA NOT TO EXCEED 75 SQ.FT. |
| 24 | LOCATION OF MID-MOUNTING POINT OF SIGNAGE AREA NOT TO EXCEED 200 SQ.FT. |
Note: All signage to be backlit channel letters, with 5" or 8" returns, raceway mounted and centered vertically on CRU frontage.
Drawing Number: A3.2
Page 37
Extracted from: 2013 12 10 Council Agenda
