Attachment 31. Plan A3.10 - Building 6 Roof Plan

December 10, 2013Page 451 section

Detailed roof plan for Building 6 and Building 7.

1 CALL TO ORDER

EAGLE CREEK VILLAGE

Watkiss Way & Helmcken Road, View Royal, BC

Architectural drawing sheet A3.10 displaying the roof plans for Building 6, featuring two distinct plan views and a corresponding legend.
Architectural drawing sheet A3.10 displaying the roof plans for Building 6, featuring two distinct plan views and a corresponding legend.

ROOF PLAN LEGEND:

  1. MECHANICAL ROOF TOP UNIT
  2. MECHANICAL ROOF TOP UNIT SCREENING
  3. MECHANICAL WELL
  4. RAISED PARAPET, INDICATED AS DASHED AREAS
  5. CANOPY

1 ROOF PLAN - BUILDING 6

SCALE: 1:200

The plan includes labels for:

  • LOADING
  • COMPACTOR
  • BALCONY
  • Grid lines: 6.A, 6.1, 6.9, 6.K

2 ROOF PLAN - BUILDING 6 (K-L)

SCALE: 1:250

The plan includes references to:

  • BUILDING 7
  • Grid lines: 6.1, 6.9, 6.K, 6.L

Drawing Information:

  • Project: BUILDING 6 - ROOF PLAN
  • Scale: As Indicated
  • Date: 25 Jan 2013
  • Project Number: 110-0083-P0-601
  • Drawing Number: A3.10
Page 45
