Attachment 32. Plan A3.11 - Building 6 Elevation

EAGLE CREEK VILLAGE - BUILDING 6 ELEVATION

Project Location: Watkiss Way & Helmcken Road, View Royal, BC
Company: OMICRON (TOTAL + BUILDING + SOLUTIONS)
Date: 03 July 2013
Drawing Number: A3.11

Architectural elevations for Building 6 of Eagle Creek Village, including East and West views, detailed with material labels and height markers.

ELEVATION - BUILDING 6 EAST

Scale: 1:200

ELEVATION - BUILDING 6 WEST

Scale: 1:200

Notes on Elevations:

SCREENING FOR LOADING
RAMP ACCESS TO MEZZ
PEDESTRIAN MEZZ

Elevation Markers:

BLG-6 TOP UP: 35.438
BLG-6 MEZZ: 31.31
BLG-6 L1: 27

ELEVATION LEGEND

Code	Description
A	DOUBLE GLAZED ALUMINUM STOREFRONT
B	DOUBLE GLAZED ALUMINUM WINDOW
C	CEMENTITIOUS BOARD & BATTEN SIDING
D	CEMENTITIOUS PANELS
E	CEMENTITIOUS HORIZONTAL PLANK SIDING
F	H.S.S. BRACES
G	ARCHITECTURAL CONCRETE
H	CULTURED STONE
I	ALUMINUM RAILING
J	ALUMINUM RAILING WITH CEMENTITIOUS PANELS
K	SHAKE STYLE ASPHALT SHINGLES
L	PAINTED DECORATIVE METAL SCREEN
M	SIGNAGE
N	DOUBLE GLAZED WINDOW WALL WITH SPANDREL PANELS
O	CAN DOOR IN GLASS PANEL
P	OUTLINE OF ROOF TOP UNIT SCREEN
Q	GLAZED OVERHEAD DOOR
S1	LOCATION OF MID-MOUNTING POINT OF SIGNAGE AREA NOT TO EXCEED 20 SQFT
S2	LOCATION OF MID-MOUNTING POINT OF SIGNAGE AREA NOT TO EXCEED 45 SQFT
S3	LOCATION OF MID-MOUNTING POINT OF SIGNAGE AREA NOT TO EXCEED 75 SQFT
S4	LOCATION OF MID-MOUNTING POINT OF SIGNAGE AREA NOT TO EXCEED 100 SQFT

Legend Note:

NOTE: All CPU signage to be face-lit channel letters with 3" or 5" returns, raceway mounted and coloured internally, or Opaque frontage.
