Attachment 33. Plan A3.12 - Building 6 Elevation & Section
December 10, 2013Page 471 section
North and South elevations for Building 6, including pylon signage details.
EAGLE CREEK VILLAGE
BUILDING 6 ELEVATION & SECTION
Project Address: Watkiss Way & Helmcken Road, View Royal BC
Date: 08 July 2013
Drawing No: A3.12
B. ELEVATION - BUILDING 6 NORTH
- Scale: 1:200
- Elevation Heights:
- BLG-6 T.O.P. UP: 25.40
- BLG-6 MEZZ: 24.11
- BLG-6 L.1: 20
- PARKING: 14.52
2. ELEVATION - BUILDING 6 SOUTH
- Scale: 1:200
- Elevation Heights:
- BLG-6 T.O.P. UP: 25.40
- BLG-6 MEZZ: 24.11
- BLG-6 L.1: 20
- PARKING: 14.52
1. SECTION - BUILDING 6
- Scale: 1:200
- Labeled Levels:
- MEZZANINE
- GROCERY STORE
- PARKING
- Elevation Heights:
- BLG-6 T.O.P. UP: 25.40
- BLG-6 MEZZ: 24.11
- BLG-6 L.1: 20
4. PYLON SIGNAGE ELEVATION
- Scale: 1:50
- Width: 12'-0"
- Support Spacing: 3'-0", 10'-0"
ELEVATION LEGEND
| No. | Description |
|---|---|
| 01 | DOUBLE GLAZED ALUMINUM STOREFRONT |
| 02 | DOUBLE GLAZED ALUMINUM WINDOW |
| 03 | CEMENTITIOUS BOARD & BATTEN SIDING |
| 04 | CEMENTITIOUS PANELS |
| 05 | CEMENTITIOUS HORIZONTAL PLANK SIDING |
| 06 | H.S.S. BRACES |
| 07 | ARCHITECTURAL CONCRETE |
| 08 | CULTURED STONE |
| 09 | ALUMINUM RAILING |
| 10 | ALUMINUM RAILING WITH CEMENTITIOUS PANELS |
| 11 | SHAKE STYLE ASPHALT SHINGLES |
| 12 | PAINTED DECORATIVE METAL SCREEN |
| 13 | SIGNAGE |
| 14 | DOUBLE GLAZED WINDOW WALL WITH SPANDREL PANELS |
| 15 | CANOPY W/ GLASS PANEL |
| 16 | OUTLINE OF ROOF TOP UNIT SCREEN |
| 17 | GLAZED OVERHEAD DOOR |
| 18 | LOCATION OF MID-MOUNTING POINT OF SIGNAGE AREA NOT TO EXCEED 45 SQ FT |
| 19 | LOCATION OF MID-MOUNTING POINT OF SIGNAGE AREA NOT TO EXCEED 45 SQ FT |
| 20 | LOCATION OF MID-MOUNTING POINT OF SIGNAGE AREA NOT TO EXCEED 45 SQ FT |
| 21 | LOCATION OF MID-MOUNTING POINT OF SIGNAGE AREA NOT TO EXCEED 150 SQ FT |
Note: All CRU signage to be face-lit channel letters, with 3" or 5" returns, raceway mounted and centered vertically on CRU frontage.
