Council Meeting/Documents/Attachment 35. Plan A3.14 - Building 7 Roof Plan and Section
Appendix

Attachment 35. Plan A3.14 - Building 7 Roof Plan and Section

December 10, 2013Page 491 section

Roof plan and cross-section for Building 7 showing the five floors and underground parking.

1 CALL TO ORDER

Eagle Creek Village: Building 7 - Roof Plan & Section

Watkiss Way & Helmcken Road, View Royal, BC

Architectural perspective rendering showing the exterior design of Building 7
Architectural perspective rendering showing the exterior design of Building 7

Roof Plan - Building 7

Roof Plan Legend

  1. MECHANICAL ROOF TOP UNIT
  2. MECHANICAL ROOF TOP UNIT SCREENING
  3. MECHANICAL WELL
  4. RAISED PARAPET, INDICATED AS SHADED AREAS
  5. CANOPY

Section - Building 7

Level Primary Use Elevation (m)
Top Roof — 40.75
Level 5 OFFICE 34.15
Level 4 OFFICE 30.25
Level 3 OFFICE 26.35
Level 2 OFFICE 22.45
Level 1 RETAIL 18.2
Parkade Level UNDERGROUND PARKING 14.9

Project Details

  • Date: 25 Jan 2013
  • Scale: 1:200 / As indicated
Page 49
