Council Meeting/Documents/Eagle Creek Village Landscape Cross Section & Fencing Details (Attachment 41)
Appendix

Eagle Creek Village Landscape Cross Section & Fencing Details (Attachment 41)

December 10, 2013Page 552 sections

Detailed specifications for rustic post and rail fencing and play area fencing along Helmcken Road.

1 CALL TO ORDER
January 25, 2013Building 5Split cedar posts

EAGLE CREEK VILLAGE

Page 55

LANDSCAPE CROSS SECTION & FENCING DETAILS

Issued for Development Permit
Date: 25 January 2013
Drawing No: L5
Scale: 1:100 / 1:15
Drawn by: car

Cross Section at Helmcken Road & South Elevation of Building #3 & Patio

Detailed landscape cross section showing the spatial relationship between Helmcken Road and Building #3
Detailed landscape cross section showing the spatial relationship between Helmcken Road and Building #3
  • Scale: 1:100
  • Section Components (from left to right):
    • Road
    • Boulevard: 1.1m
    • Sidewalk: 1.7m
    • Buffer Planting: 7.4m
    • Patio: 3.0m
  • Building #3 Details:
    • Property line
    • Existing grade
    • mfe: 20.0
    • Parkade: 16.95

Rustic Post & Rail Fence Along North East Property Line

  • Scale: 1:25
  • Specifications:
    • 2" x 5" horizontal cedar boards
    • Paired split cedar posts spaced to pinch cedar boards
    • Height: 1.1m

Play Area Fence Fronting Helmcken Road

  • Scale: 1:25
  • Height: 1.1m
Page 55
