Eagle Creek Village Grading Plan (Attachment 43)

EAGLE CREEK VILLAGE - GRADING PLAN

Site Grading Plan for Eagle Creek Village showing building locations, site contours, road layouts for Watkiss Way and Helmcken Road, and a roundabout detail.

Project Information

Project: EAGLE CREEK VILLAGE
Developer: OMICRON DEVELOPMENT INC.
Consulting Firm: WESTBROOK Consulting Ltd.
Address: #115 - 555 Goldstream Ave., Victoria, BC V8B 0J3
Telephone: 250-391-8592 | Facsimile: 250-391-8593
Project No.: 2823
Sheet: 2 of 3
Drawing No.: 2823-DP02
Date: MAY 2012
Scale Horz.: 1:500

Revisions

No.	Description	Date	Sign
1	REVISED FOR NEW BUILDING LAYOUT	2012-10-18	FC
2	ISSUED FOR DEVELOPMENT PERMIT	2013-01-25	FC
3	RE-ISSUED FOR DEVELOPMENT PERMIT	2013-10-25	FC

Legend

Proposed services shown bold

WATER: Solid line
SEWER: Dashed line with "S"
DRAIN: Dashed line with "D"
NATURAL GRADE: Dotted line
CULVERT: Double parallel lines
HEADWALL: Rectangular symbol at pipe end
GAS: Line with "G"
CURB: Double line
SIDEWALK: Stippled/hatched area
EDGE PAVE.: Dashed line
BUSHLINE: Scalloped line
TREE: Circular foliage symbol
EXISTING U/S UTIL.: Thin line
PROPOSED U/S UTIL.: Bold line
LIGHT STANDARD: Circle with four rays
POWER POLE: Circle with cross
ANCHOR: Arrow symbol
MANHOLE: Circle
CLEANOUT: Square
CATCHBASIN: Grated rectangle
ROAD SIGN: Square on post symbol
HYDRANT: Circle with internal cross
VALVE: Bowtie symbol
METER: Square with "M"
REDUCER: Triangular symbol
MONUMENT: Diamond symbol
LOT PIN: Circle with dot
LEAD PLUG: Small square

Grading Legend

Existing ground contour (0.5m interval): Light dashed line
Proposed finished grade contour (0.2m interval): Bold dashed line
Proposed finished grade elevation: Numerical value (e.g., +20.00)
Proposed park contour: Green dashed line

General Notes

THE LOCATION AND ELEVATION OF EXISTING UNDERGROUND SERVICES ON THIS DRAWING MAY NOT BE ACCURATE OR COMPLETE. THE ACTUAL HORIZONTAL AND VERTICAL LOCATIONS MUST BE CONFIRMED BY UTILITY COMPANIES AND THE CONTRACTOR PRIOR TO THE TO THE START OF ANY EXCAVATIONS.

Site Details

Building Finished Elevations (MFE)

Building 1: MFE 20.00
Building 2: MFE 21.00
Building 3: MFE 21.00
Building 4: MFE 22.00
Building 5: MFE 23.00
Building 6: MFE 20.00
Building 7: MFE 20.00 (Refer to architectural drawings for stair & ramp details)
Building 8: MFE 20.00 (Refer to architectural drawings for stair & ramp details)

Infrastructure and Features

Watkiss Way: Access road running north-south on the west side of the site.
Helmcken Road: Access road running east-west on the south side of the site.
Hospital Access: Located at the northwest corner of the site.
Loading Area: Located behind Building 6.
Bus Stop: Located on Watkiss Way.
