Attachment 6. Plan A0.2 – Site Plan

December 10, 2013Page 1171 section

Architectural site plan for the proposed commercial buildings and parking layout.

1 CALL TO ORDER
November 28, 2013D'Ambrosio Architecture + Urbanism

Site Plan - Lakeside Village Commercial

Detailed site plan for the Lakeside Village Commercial development in View Royal, showing four proposed commercial buildings (A, B, C, and D), existing residential buildings, parking areas, and surrounding roads including Six Mile Road, Presley Place, and Nursery Hill Road.
Detailed site plan for the Lakeside Village Commercial development in View Royal, showing four proposed commercial buildings (A, B, C, and D), existing residential buildings, parking areas, and surrounding roads including Six Mile Road, Presley Place, and Nursery Hill Road.

Project Information

Field Details
Project Lakeside Village Commercial
Location View Royal
Sheet Title Site Plan
Date 13.11.28
Scale 1:250
Project No. 1303
Drawing File 1303_LVC_131102 DW
Drawn By d/ng/ng
Checked By fda
Revision A
Sheet No. A0.2
Application Type DEVELOPMENT PERMIT APPLICATION

Site Details and Labels

Proposed Structures:

  • Commercial (A)
  • Commercial (B)
  • Commercial (C)
  • Commercial (D)
  • WC (located between Commercial C and D)
  • Bridge (connecting Commercial A/C area to Commercial B/D area)

Parking and Access:

  • Commercial Parking: 60 stalls (30 sq m / stall + 1 loading)
  • Presley Place (Private Lane)
  • Six Mile Road
  • Nursery Hill Road (Private Lane)

Existing Context:

  • Existing Residential (two large building footprints)
  • Existing Multi-Family Housing (located to the north and south of the site)
  • Park (located to the northwest)

Site Specifications and Setbacks:

  • Property Line
  • Setback from Private Road
  • Setback from Sidewalk - Proposed
  • 4000 Setback
  • 4800 Setback
  • Hydrant
  • Line of Building Footprint
  • Line of Roof Edge
  • Topographical markers (e.g., 34 FG, 33.5 FG, 23.5 FG)
  • North Arrow and Graphic Scale (Meters)
