Attachment 7. Plan A1 – Lower Level

December 10, 2013Page 1181 section

Architectural floor plan for the lower level commercial units.

1 CALL TO ORDER
August 2, 2013

Lakeside Village Commercial - View Royal

Development Permit Application: Lower Level

Site plan drawing for the Lakeside Village Commercial project, showing the layout of the lower level. The plan includes two proposed commercial buildings, existing residential structures, a parkade, and infrastructure details like roads, setbacks, and hydrants.
Site plan drawing for the Lakeside Village Commercial project, showing the layout of the lower level. The plan includes two proposed commercial buildings, existing residential structures, a parkade, and infrastructure details like roads, setbacks, and hydrants.
Project Details Information
Architectural Firm D'AMBROSIO architecture + urbanism
Address 2043 Jutland Road, Victoria BC, Canada V8T 5H1
Project Title Lakeside Village Commercial - View Royal
Sheet Title Lower Level
Project No. 1308
Drawing File 1308 LSC 130802 DP
Date 13.08.02
Scale 1:250
Sheet No. A1

Site Plan Components

  • Proposed Commercial Space:
    • Lower Commercial (A): 265m²
    • Lower Commercial (B): 161m² / 122m²
  • Existing and Future Residential:
    • Existing Residential - Level 1
    • Existing Residential Parkade
    • Existing Multi-Family Housing
    • Future Multi-Family Housing
  • Roads and Infrastructure:
    • Six Mile Road
    • Nursery Hill Road (Private Lane)
    • Presley Place (Private Lane)
    • Decorative Pavers
    • Hydrant
  • Site Boundaries and Setbacks:
    • Property Line
    • Setback from Private Road
    • Setback from Sidewalk - Proposed
  • Land Use:
    • Park area adjacent to property line
Page 118
