Attachment 8. Plan A2 – Main Level

December 10, 2013Page 1191 section

Architectural floor plan for the main level commercial units.

1 CALL TO ORDER
August 2, 2013

Lakeside Village Commercial - Main Level

Site plan drawing for Lakeside Village Commercial showing building footprints, surrounding roads, and landscaping.
Site plan drawing for Lakeside Village Commercial showing building footprints, surrounding roads, and landscaping.

Project Information

Field Detail
Project Name Lakeside Village Commercial
Client Muir Royal
Sheet Title Main Level
Date 13.08.02
Scale 1:250
Drawn By flk
Checked By fda
Project No. 1106
Sheet No. A2
Drawing File 1106 LVC 130822 DM

Site Plan Details

Proposed Commercial Buildings:

  • Main Commercial (A): 400 m²
  • Main Commercial (B): 151.0 m²
  • Main Commercial (C): 181.0 m²
  • Lower Commercial (D): 173.0 m²

Existing Structures and Adjacent Areas:

  • Existing Residential - Level 1
  • Existing Residential - Level 2
  • Existing Multi-Family Housing
  • Future Multi-Family Housing
  • Park area

Surrounding Infrastructure:

  • Six Mile Road
  • Nursery Hill Road (Private Lane)
  • Presley Place (Private Lane)
  • Property Line
  • Setback from Private Road
  • Setback from Sidewalk - Proposed
  • Hydrant locations (marked "Hydrant" and "CP Hydrant")

Notes:

  • The plan includes a North arrow and a graphic scale.
  • The document is noted as a Development Permit Application.
