Attachment 9. Plan A3 – Upper Level

December 10, 2013Page 1201 section

Architectural floor plan for the upper level commercial units.

1 CALL TO ORDER
August 2, 2013

Lakeside Village Commercial - Upper Level

Site plan for the upper level of Lakeside Village Commercial, showing building footprints for Upper Commercial (C) and (D), parking layout, existing residential structures, and adjacent roads.
Site plan for the upper level of Lakeside Village Commercial, showing building footprints for Upper Commercial (C) and (D), parking layout, existing residential structures, and adjacent roads.

Site Plan Details

  • Commercial Parking: 53 stalls (24 regular + 28 small + 1 loading)
  • Upper Commercial (C): 1078 m²
  • Upper Commercial (D): 180 m²
  • Existing Residential: Existing Residential - Level 2, Existing Residential - Level 3
  • Surrounding Context:
    • Future Multi-family housing
    • Existing Multi-family housing
    • Park
  • Roads and Access:
    • Presley Place (Private Lane)
    • Six Mile Road
    • Nursery Hill Road (Private Lane)
  • Site Markers:
    • Property line
    • Setback from private road
    • Setback from sidewalk - proposed
    • Hydrant
    • CRD water main right of way
    • Terrace
    • Roof areas

Project Information

Field Details
Project Lakeside Village Commercial
Location View Royal
Application Type Development Permit Application
Sheet Title Upper Level
Date 13.08.02
Scale 1:250
Project No. 1318
Drawing File 1318 LVC 130802 DP.dwg
Drawn by rk
Chk'd by fda
Sheet No. A3
Architecture Firm D'Ambrosio architecture + urbanism
Address 2042 Juniper Road, Victoria BC V8X 2E2
Phone (250) 384-2400
