Council Meeting/Documents/Attachment 10. Plan A4 – Roof Plan
Appendix

Attachment 10. Plan A4 – Roof Plan

December 10, 2013Page 1211 section

Architectural plan showing roof structures and drainage paths.

1 CALL TO ORDER
August 2, 2013

Lakeside Village Commercial - View Royal

Detailed architectural site plan labeled "Roof Plan" showing the proposed development layout. The plan includes several buildings marked "ROOF", "EXISTING RESIDENTIAL - LEVEL 3", and "EXISTING RESIDENTIAL - ROOF". It details a "COMMERCIAL PARKING" area with 53 stalls (20 regular, 32 small, and 1 loading), surrounding roads including "PRESLEY PLACE (PRIVATE LANE)", "SIX MILE ROAD", and "NURSERY HILL ROAD (PRIVATE LANE)", and adjacent land uses such as "FUTURE MULTI-FAMILY HOUSING", "EXISTING MULTI-FAMILY HOUSING", and a "PARK". Technical notations include property lines, setbacks, hydrants, a CRD water main right of way, and various site elevations.
Detailed architectural site plan labeled "Roof Plan" showing the proposed development layout. The plan includes several buildings marked "ROOF", "EXISTING RESIDENTIAL - LEVEL 3", and "EXISTING RESIDENTIAL - ROOF". It details a "COMMERCIAL PARKING" area with 53 stalls (20 regular, 32 small, and 1 loading), surrounding roads including "PRESLEY PLACE (PRIVATE LANE)", "SIX MILE ROAD", and "NURSERY HILL ROAD (PRIVATE LANE)", and adjacent land uses such as "FUTURE MULTI-FAMILY HOUSING", "EXISTING MULTI-FAMILY HOUSING", and a "PARK". Technical notations include property lines, setbacks, hydrants, a CRD water main right of way, and various site elevations.

Project Information

  • Project Title: Lakeside Village Commercial
  • Location: View Royal
  • Sheet Title: Roof Plan
  • Date: 13.08.12
  • Scale: 1:250
  • Architect: D’AMBROSIO architecture + urbanism (2003 Jutland Road, Victoria BC)
  • Project No: 1324
  • Sheet No: A4
  • Drawing File: 1324 LSC 130802 Roof Plan.dwg
  • Drawn by: th
  • Checked by: fda

Site Plan Details

  • Parking: 53 stalls total (20 reg / 32 sm + 1 loading)
  • Setbacks:
    • Setback from private road: 1500
    • Setback from sidewalk - proposed: 4000
  • Surrounding Context:
    • Six Mile Road
    • Presley Place (Private Lane)
    • Nursery Hill Road (Private Lane)
    • Future Multi-Family Housing
    • Existing Multi-Family Housing
    • Park
  • Infrastructure:
    • CRD Water Main Right of Way
    • Fire Hydrants
    • 10% Slope area
    • Site elevations (FG) ranging from approximately 31.9 to 46.83
Page 121
