Council Meeting/Documents/Attachment 11. Plan A5 – Sections
Appendix

Attachment 11. Plan A5 – Sections

December 10, 2013Page 1221 section

Cross-section drawings of the development illustrating building height relative to the slope.

1 CALL TO ORDER
August 2, 2013

Sections

Architectural sections A and B for Lakeside Village Commercial, showing site topography, building levels, and watermain alignments.
Architectural sections A and B for Lakeside Village Commercial, showing site topography, building levels, and watermain alignments.

Section A

Scale 1:500

This section depicts the site profile from a property line across to Six Mile Road.

  • Key Labels: Property Line, Setback, Line of Existing Grade, Water Main Right of Way, Top of Watermain, Six Mile Road.
  • Note: GROUND COVER OVER WATERMAIN WILL NOT EXCEED THAT RECOMMENDED BY CRD.

Section B

Scale 1:500

This section shows building elevations and site grades relative to the existing terrain and infrastructure.

  • Building Levels:
    • 33.02 Roof
    • 30.65 LEVEL 1
    • 28.02 BICYCLE
    • 30.02 LEVELS
    • 27.02 BICYCLE
  • Finished Grades (FG):
    • 33 FG
    • 30 FG
    • 27 FG
    • 24 FG
  • Watermain Elevations (Top of Watermain):
    • 25.8m+
    • 26m+
    • 27.8m+
    • 26.4m+
    • 24.8m+
  • Other Labels: Property Line, Setback, Line of Existing Grade.

Project Information

DEVELOPMENT PERMIT APPLICATION

Field Details
Architect D'AMBROSIO architecture + urbanism
Address 2043 Julian Street, Victoria, BC Canada V8R 1H2
Project Lakeside Village Commercial
Location View Royal
Sheet Title Sections
Date 13.08.02
Scale 1:200
Drawn by lfk
Check by fda
Project No. 1228
Sheet No. A5
Drawing File 1228 LVC 130802 DWG
Page 122
Extracted from: 2013 12 10 Council Agenda
