Supplemental section drawing illustrating ground cover over the CRD watermain.

1 CALL TO ORDER
August 13, 2013

Lakeside Village Commercial - Section

Architectural section drawing showing building profiles, heights, finished grades, and a water main right-of-way.
Architectural section drawing showing building profiles, heights, finished grades, and a water main right-of-way.

NOTE: Finished grades illustrated above have been slightly adjusted from those submitted with the DP application of Aug. 2, 2013. Due to the complex topography of the site these will continue be refined prior to Building Permit application.

NOTE: GROUND COVER OVER WATERMAIN WILL NOT EXCEED THAT RECOMMENDED BY CRD.

Project Information

DEVELOPMENT PERMIT APPLICATION - supplemental information

  • Project Name: Lakeside Village Commercial
  • Location: View Royal
  • Architect: D'AMBROSIO architecture + urbanism
  • Address: 2960 Jutland Road, Victoria BC Canada V8T 5K2
  • Tel: 250 384 2400
  • Fax: 250 384 7393
  • Email: mail@fdarc.ca
  • Web: www.fdarc.ca
  • Sheet Title: Section
Field Detail
Date 13.08.09
Scale 1:200
Drawn by tfk
Checked by fda
Sheet No. Ask 4
Project No. 1328
Drawing File 1328 LVC 130502 DP rev
Page 132
