Exhibit 1: Site Plan - Lakeside Village

December 10, 2013Page 1471 section

Attachment 22: Illustrative site plan showing the layout of commercial and residential buildings at 430 Six Mile Road.

1 CALL TO ORDER

430 Six Mile RoadD'Ambrosio Architecture + Urbanism

EXHIBIT 1: SITE PLAN

Illustrative Site Plan showing a development layout with residential and commercial buildings, a park area, and commercial parking. The property is bounded by Six Mile Road, Nursery Hill Road (Private Lane), and Road A (Private Lane).

Site Plan Features

PARK
RESIDENTIAL
COMMERCIAL
COMMERCIAL PARKING
SIX MILE ROAD
NURSERY HILL ROAD (PRIVATE LANE)
ROAD A (PRIVATE LANE)
EXISTING MULTI-FAMILY HOUSING
FUTURE MULTI-FAMILY HOUSING
PROPERTY LINE
SETBACK FROM PRIVATE ROAD
SETBACK FROM SIDEWALK + RIGHT OF WAY

D’AMBROSIO ARCHITECTURE + URBANISM Illustrative Site Plan A0

Page 147
