Attachment 6: Plan A - Submitted Proposal for 138 St. Giles Street

December 10, 2013Page 1692 sections

Site plan 'Plan A' showing the applicant's preferred subdivision layout and building envelopes.

1 CALL TO ORDER
Lot 1: 849.99 SQ.M.Lot 2: 756.63 SQ.M.

PLAN A - submitted proposal for property

Page 169

138 ST. GILES STREET

Detailed survey plan showing a proposed subdivision of 138 St. Giles Street into two parcels. Lot 1 is 849.99 square meters and Lot 2 is 756.63 square meters. The plan includes property line bearings, distances, an existing house footprint with specific spot elevations, and identifies the street edge and waterfront boundary.
Detailed survey plan showing a proposed subdivision of 138 St. Giles Street into two parcels. Lot 1 is 849.99 square meters and Lot 2 is 756.63 square meters. The plan includes property line bearings, distances, an existing house footprint with specific spot elevations, and identifies the street edge and waterfront boundary.

Proposed Subdivision

PROPOSED SUBDIVISION OF LOT 2 SECTION 9 PLAN 15774 ESQUIMALT DISTRICT

  • Proposed Lot 1: 849.99 SQ.M.
  • Proposed Lot 2: 756.63 SQ.M.
  • Note: SUBTRACT 10° 31' TO GET TRUE NORTH

Grade Calculations

  • (4.41 + 4.35) / 2 x 10.5 = 45.99
  • (4.35 + 4.46) / 2 x 10.5 = 46.252
  • (4.46 + 4.46) / 2 x 2.4 = 10.704
  • (4.46 + 4.03) / 2 x 1.4 = 5.943
  • (4.03 + 4.03) / 2 x 11.4 = 45.942
  • (4.03 + 3.94) / 2 x 8.5 = 33.8725
  • (3.94 + 3.65) / 2 x 4.8 = 18.216
  • (3.65 + 3.58) / 2 x 5.8 = 20.967
  • (3.58 + 3.94) / 2 x 4.8 = 18.048
  • (3.94 + 3.35) / 2 x 14.4 = 52.488
  • (3.35 + 3.70) / 2 x 3.0 = 10.575
  • (3.70 + 4.0) / 2 x 4.8 = 18.48
  • (4.0 + 4.08) / 2 x 5.8 = 23.432
  • (4.08 + 4.41) / 2 x 11.4 = 48.393
  • (3.70 + 3.75) / 2 x 3.0 = 11.175
  • (3.75 + 3.70) / 2 x 3.0 = 11.175
  • (3.70 + 3.70) / 2 x 1.0 = 3.7
  • (3.35 + 3.20) / 2 x 11.0 = 36.025
  • (3.20 + 3.20) / 2 x 14.8 = 47.36
  • (3.20 + 3.15) / 2 x 3.1 = 9.8425
  • (3.15 + 3.30) / 2 x 10.4 = 33.54
  • (3.30 + 3.13) / 2 x 3.1 = 9.9665
  • (3.13 + 3.10) / 2 x 14.8 = 46.101
  • (3.10 + 3.35) / 2 x 11.0 = 35.475
  • (4.41 + 4.08) / 2 x 5.8 = 24.621
  • 789.491 / 209.45 = 3.77
  • AVG GRADE = 3.77
