Site plan 'Plan B' representing the town's suggestion to divide the lot down the middle.

1 CALL TO ORDER
Lot 1: 804.88 SQ.M.Lot 2: 801.75 SQ.M.

PLAN B

  • recommendation from View Royal to divide lot down the middle
Map showing the proposed subdivision of Lot 2, Section 9, Plan 15774, Esquimalt District, into two parcels at 138 St. Giles Street.
Map showing the proposed subdivision of Lot 2, Section 9, Plan 15774, Esquimalt District, into two parcels at 138 St. Giles Street.

Proposed Subdivision Details

R1-A ZONING PROPOSED SUBDIVISION OF LOT 2 SECTION 9 PLAN 15774 ESQUIMALT DISTRICT

Address: 138 ST. GILES STREET

Lot Areas:

  • Parcel 1: 804.88 SQ.M.
  • Parcel 2: 801.75 SQ.M.

Dimensions:

  • Street Frontage (Edge of Pavement):
    • Parcel 1: 15.08 M
    • Parcel 2: 15.08 M
  • Water Frontage:
    • Parcel 1: 15.93 M
    • Parcel 2: 15.50 M
  • Boundary Lines:
    • Eastern boundary: 41.712 M (bearing 3° 09' 10") and 13.367 M (bearing 177° 09' 25")
    • Center dividing line: 40.16 M
    • Western boundary: 55.694 M (bearing 180° 0' 0")
    • South-western corner: 5.79 M (bearing 180° 0' 0")
    • North-western corner: 5.79 M (bearing 3° 09' 10")
