Attachment 3: Site Plan - D'Ambrosio Architecture + Urbanism

Lakeside Village Commercial Site Plan

Site Plan Notes

• A: CONFIRMATION THAT FDC IS WITHIN 45M REQUIREMENT AND THAT PROPOSED ADDITIONAL FIRE HYDRANT IS NOT REQUIRED.
• B: RELOCATED LOADING TO PROVIDE ADDITIONAL ACCESSIBLE PARKING STALL AT COURTYARD LEVEL.
• C: PER FIRE DEPARTMENT COMMENTS, RELOCATED FDC.
• D: REVISED COURTYARD SWALE IN ACCORDANCE WITH CRD REQUIREMENTS FOR LAND OVER TOP OF MAJOR WATER LINES INCLUDING PLANTINGS, CROSS ACCESS AND UPDATED PROGRAMMING.
• E: PER TOWN PLANNING COMMENTS, PIPING OF STORM WATER INSTEAD OF SWALE AT GAS LINE LOCATION. PER FIRE DEPARTMENT COMMENTS, SECOND ACCESS TO COMMERCIAL BUILDING "A".
• F: RELOCATED ACCESSIBLE STALL CLOSER TO LIFT (BUILDING ENTRANCE).
• G: PROVIDED SCREENED GARBAGE AND RECYCLING AT UPPER LEVEL *PREVIOUS LOCATION OF RETAINING WALL SHOWN DASHED.
• H: RECONFIGURED DRIVE APPROACH FROM PRESLEY PLACE AND PARKING ROW FOR IMPROVED ACCESS AND TO MAXIMIZE STALL COUNT.
• I: ADDITIONAL PARKING SPACES TO EASE VARIANCE DISPARITY.
• J: PER ENGINEERING COMMENTS, ACCESS BRIDGE REVISED TO GRADED CULVERT.
• K: PER ENGINEERING AND FIRE DEPARTMENT COMMENTS, EXISTING FIRE HYDRANT RELOCATED OUT OF SWALE.
• L: OUTLINE OF PROPOSED DECK AT SECOND LEVEL.
• M: EXTEND OF REQUESTED VARIANCE FOR SOLAR SHADING CANOPY PROJECTION INTO YARD SETBACK.

Plan Details and Labels

• Buildings and Zones: Commercial (A), Commercial (B), Commercial (C), Commercial (D), Existing Residential, Existing Multi-Family Housing, Park.
• Parking: Commercial Parking - Relocated 60 stalls (30reg/2h.c./27sm + 1 loading), Relocated Loading Area.
• Roads and Access: Presley Place (Private Lane), Nursery Hill Road (Private Lane), Six Mile Road, Fire Department Alternate Access Path, Concrete/Paved Accessible Walkway.
• Key Features: Bridge, WC, Screened Garbage and Recycling, Existing Fire Hydrant Location, Approx. New Hydrant Location, Property Line, Setback From Private Road, Setback From Sidewalk - Proposed.
