Council Meeting/Documents/Attachment 4: Portage Park Residences - Level 5 & Roof Plans, Unit Plans, Elevations, and Sections
Appendix

Attachment 4: Portage Park Residences - Level 5 & Roof Plans, Unit Plans, Elevations, and Sections

January 18, 2022Pages 185–1918 sections

A set of architectural drawings by Urban West Architecture for the Portage Park Residences project, detailed for rezoning purposes.

167, 169 & 171 Island Highway, View Royal, BCUrban West ArchitectureIssued for Rezoning on 2021-12-03Includes plans for unit types A3, B1, B2, B2a, B3, B4, C1, C2, C3, C4, and D1

Portage Park Residences

Address: 167, 169 & 171 Island Highway, View Royal, BC Project Number: 2021-01 Architect: Urban West Architecture (UWA) Revision Date: 2021 12 03 - Issued for Rezoning

Page 185–191

A102: Level 5 & Roof Plans

1 Level 5 Plan

Scale: 1:150

Level 5 floor plan showing residential units 501 through 509, central corridor, elevator, stairs, and various balcony configurations
Level 5 floor plan showing residential units 501 through 509, central corridor, elevator, stairs, and various balcony configurations

2 Roof Plan

Scale: 1:150

Roof plan showing the building footprint, roof slopes, and mechanical/access structures
Roof plan showing the building footprint, roof slopes, and mechanical/access structures
Page 185–191

A150: Unit Plans

Drawing Unit Type Quantity Percentage Total Area
1 TYPE A3 - JR. 1 BEDROOM 20 24% 472 SQ. FT.
2 TYPE B1 - 1 BEDROOM 4 5% 572 SQ. FT.
3 TYPE B2 - 1 BEDROOM + FLEX 24 29% 572 SQ. FT.
4 TYPE B2a - 1 BEDROOM + FLEX 8 10% 548 SQ. FT.
5 TYPE B3 - 1 BEDROOM 1 1% 568 SQ. FT.
Five detailed floor plans for unit types A3, B1, B2, B2a, and B3, including dimensions for rooms such as great rooms, bedrooms, flex spaces, and balconies
Five detailed floor plans for unit types A3, B1, B2, B2a, and B3, including dimensions for rooms such as great rooms, bedrooms, flex spaces, and balconies
Page 185–191

A151: Unit Plans

Drawing Unit Type Quantity Percentage Total Area
1 TYPE B4 - 1 BEDROOM 8 10% 617 SQ. FT.
2 TYPE C2 - 2 BEDROOM 8 10% 893 SQ. FT.
3 TYPE C1 - 2 BEDROOM 1 1% 816 SQ. FT.
4 TYPE C3 - 2 BEDROOM + FLEX 4 5% 979 SQ. FT.
Four detailed floor plans for unit types B4, C1, C2, and C3, showing layouts for kitchens, bathrooms, ensuites, and balconies
Four detailed floor plans for unit types B4, C1, C2, and C3, showing layouts for kitchens, bathrooms, ensuites, and balconies
Page 185–191

A152: Unit Plans

Drawing Unit Type Quantity Percentage Total Area
1 TYPE C4 - 3 BEDROOM 3 4% 1131 SQ. FT.
2 TYPE D1 - 2 BEDROOM + FLEX 1 1% 1088 SQ. FT.
Two detailed floor plans for large unit types C4 and D1, featuring multiple bedrooms, ensuites, and significant balcony space
Two detailed floor plans for large unit types C4 and D1, featuring multiple bedrooms, ensuites, and significant balcony space
Page 185–191

A200: Elevations - Southeast & Southwest

Material Legend

  • 01: Aluminum Soffit (Wood Texture)
  • 02: Painted Fibre Cement Panel (White)
  • 03: Painted Fibre Cement Board and Battens (White)
  • 04: Brick Veneer (Blonde)
  • 05: Painted Fibre Cement Panel (Black)
  • 06: Architectural Board Form Concrete
  • 07: Aluminum Storefront Windows (Black)
  • 08: Vinyl Windows (White)
  • 09: Steel Picket Guardrail (White)
  • 10: Glass Guardrail (Transparent)

1 Southeast Elevation (Pub Side)

Scale: 1:150

Southeast elevation showing five residential levels above grade, vertical window treatments, and balcony structures
Southeast elevation showing five residential levels above grade, vertical window treatments, and balcony structures

2 Southwest Elevation (Island Highway)

Scale: 1:150

Southwest elevation showing the building's frontage onto Island Highway, including the parkade entry and site landscaping
Southwest elevation showing the building's frontage onto Island Highway, including the parkade entry and site landscaping
Page 185–191

A201: Elevations - Northwest & Northeast

1 Northwest Elevation (Park Side)

Scale: 1:150

2 Northeast Elevation (Park Side)

Scale: 1:150

Page 185–191

A300: Sections

1 Cross Section

Scale: 1:150

2 Cross Section

Scale: 1:150

3 Long Section

Scale: 1:150

Building Height Data

  • To Roof: 16.5m (EL: 31.3m)
  • To Level 5: 13.3m (EL: 27.6m)
  • To Level 4: 10.1m (EL: 24.4m)
  • To Level 3: 6.9m (EL: 21.2m)
  • To Level 2: 3.7m (EL: 18.0m)
  • To Level 1: 0.5m (EL: 14.8m)
  • Grade: 0.0m (EL: 13.55m)
  • Level P1: -3.0m (EL: 10.25m)
Page 185–191
