PLANS - 157 VIEW ROYAL AVE - POTTING SHED
Architectural floor plans and elevation drawings for a proposed potting shed at 157 View Royal Avenue.
157 VIEW ROYAL AVE - POTTING SHED
Project Address: 157 VIEW ROYAL AVE, VICTORIA, BC V9B 1A6 Project Number: 157 VIEW ROYAL AVE Designed By: LEIF GUSTAVSON, ARCHITECTURAL TECHNOLOGIST A.I.B.C. Contact: LG@STUDIOLEAF.CA | 250 480 9439
Issue Schedule
| # | DATE | BY | DESCRIPTION |
|---|---|---|---|
| 1 | 25/05/20 | LG | FOR CLIENT REVIEW |
| 2 | 25/06/02 | LG | FOR CLIENT REVIEW |
| 3 | 25/08/01 | LG | ISSUED FOR DP |
Sheet A1: PLANS
Scale: 1:48
1. FLOOR PLAN
The floor plan details the layout for a potting shed, pool bathroom, and outdoor shower area.
- Potting Shed: 7061 mm x 3658 mm interior space. Features include a utility sink, hot water tank (HWT), floor drain, and "window above" notation.
- Pool Bathroom: 2235 mm x 2743 mm interior space. Features include a floor drain, "window above" notation, and a doorway with a "DN 1 R @ 200mm" step.
- Outdoor Shower: 1829 mm wide area with "EQ" (equal) spacing notations.
- Structural and Site Elements:
- 8"x8" posts.
- Locations for a tennis court and pool.
- Existing fence and posts.
- Exterior trench drain and downspout.
- Elevation benchmarks: 12.49 m, 11.53 m, 11.50 m, 11.49 m, 12.47 m.
2. ROOF PLAN
Details the roofing structure for the building.
- Material: Standing seam metal roofing.
- Slope: 1.2 : 12 pitch indicated for both main roof sections.
3. SECTION
A cross-sectional view of the building structure showing vertical dimensions and interior components.
- Structural Notes:
- New subfloor for plumbing.
- Floor drain.
- Trench drain.
- Existing 8" concrete slab.
- Vertical Dimensions:
- Exterior height markers: 1299 mm, 2543 mm, 3249 mm.
- Interior/Structural heights: 762 mm, 2134 mm, 406 mm, 51 mm.
Sheet A2: ELEVATIONS
Scale: 1:48
1. EAST ELEVATION
Shows the exterior profile of the building and fence from the east.
2. NORTH ELEVATION
Exterior view from the north, showing the building's relationship to the tennis court.
- Note: Align ridge to existing fence.
3. SOUTH ELEVATION
Exterior view from the south, showing the building's relationship to the tennis court.
4. WEST ELEVATION
Exterior view from the west side of the potting shed and outdoor shower area.
- Vertical Dimensions:
- Floor Plan: 0 mm
- Base: 200 mm
- Door/Opening Height: 2159 mm
- Total Structure Height: 4214 mm
- Notes:
- Align ridge to existing fence.
- Outdoor shower head location.
- Downspout: Tie into existing storm.
