Retaining Wall Elevation and Sections (S1.9a)

ERSKINE LANE MULTIFAMILY - BUILDING D

9 ERSKINE LANE, VIEW ROYAL BC WESTBURAN DEVELOPMENTS LTD

RETAINING WALL ELEVATION AND SECTIONS

Herold Engineering 600-1112 Fort St., Victoria, BC V8V 4V6 Tel: 250-590-4115 Fax: 250-590-4392 mail@heroldengineering.com www.heroldengineering.com

Issues

Drawing Details

• DESIGNED: DDB
• DESIGN REVIEW: LLR
• DRAFTED: DM
• DRAFTING REVIEW: DAH
• PROJECT No.: 4584-011
• SCALE: AS SHOWN
• HEL DRAWING No.: S1.9a
• PERMIT No.: n/a
• REVISION: 01

Retaining Wall Elevations

A - RETAINING WALL ELEVATION

• Scale: 1:100
• Overall Dimension: 25181
• Key Elevations:
  • 20.03m T.O. WALL
  • 19.13m T.O. FTG
  • 17.97m T.O. FTG
  • 20.04m T.O. WALL
  • 17.99m T.O. FTG

B - RETAINING WALL ELEVATION

• Scale: 1:40
• Dimensions: 16648, 27374
• Key Elevations:
  • 22.22m T.O. WALL
  • 20.60m T.O. WALL
  • 17.89m T.O. FTG
  • 18.28m T.O. FTG
  • 20.14m T.O. WALL
  • 18.28m T.O. FTG
  • 17.89m T.O. FTG
  • 20.05m T.O. WALL
  • 20.05m T.O. WALL
  • 17.50m T.O. FTG

C - RETAINING WALL ELEVATION

• Scale: 1:50
• Dimensions: 16319, 9057
• Key Elevations:
  • 20.02m T.O. WALL
  • 17.72m T.O. FTG

D - RETAINING WALL ELEVATION

• Scale: 1:50
• Dimension: 3758
• Key Elevations:
  • 20.05 T.O. WALL
  • 17.85m T.O. FTG
  • 20.05 T.O. WALL
  • 17.80m T.O. FTG

E - RETAINING WALL ELEVATION

• Scale: 1:50
• Dimension: 3706
• Key Elevations:
  • 19.99m T.O. WALL
  • 17.90m T.O. FTG
  • 19.99m T.O. WALL
  • 17.83m T.O. FTG

F - RETAINING WALL ELEVATION

• Scale: 1:50
• Dimension: 4599
• Key Elevations:
  • 20.04m T.O. WALL
  • 17.99m T.O. FTG
  • 20.02m T.O. WALL
  • 17.95m T.O. FTG
