PLANS - 157 VIEW ROYAL AVE - POTTING SHED

157 VIEW ROYAL AVE - POTTING SHED

Project Information

• Project Name: 157 VIEW ROYAL AVE - POTTING SHED
• Project Address: 157 VIEW ROYAL AVE, VICTORIA, BC V9B 1A6
• Designed By: LEIF GUSTAVSON, ARCHITECTURAL TECHNOLOGIST A.I.B.C.
• Contact: LG@STUDIOLEAF.CA | 250 480 9439

Issue Schedule

Sheet Information

• Sheet Title: PLANS
• Scale: 1:48
• Sheet Number: A1

1 FLOOR PLAN

Scale: 1:48

The floor plan details the following areas and features:

• Potting Shed: Main room measuring 7061 mm in length and 3658 mm in width. It includes a utility sink, floor drain, and hot water tank (HWT). The roof pitch is indicated as 1.2:12.
• Pool Bathroom: Enclosed room measuring 2235 mm by 2743 mm, featuring a window above.
• Outdoor Shower: External area measuring 1829 mm in width.
• Structural and Site Features:
  • 8"x8" posts and a downspout.
  • External trench drain.
  • Adjacent tennis court and pool area.
  • Existing fence and posts.
• Specified Elevations: 12.49 m, 12.47 m, 11.53 m, 11.50 m, and 11.49 m.

2 ROOF PLAN

Scale: 1:48

The roof plan specifies:

• Material: Standing seam metal roofing.
• Pitch: Roof slopes are marked at 1.2:12.
• The plan shows the structural footprint of the Potting Shed, Pool Bathroom, and Outdoor Shower.

3 SECTION

Scale: 1:48

The cross-section drawing details the vertical construction:

• Foundation: Existing 8" concrete slab with a new subfloor for plumbing.
• Drainage: Internal floor drain and an external trench drain.
• Roof: Pitch of 1.2:12.
• Vertical Dimensions:
  • Interior wall heights: 2543 mm and 2134 mm.
  • Maximum interior height from slab to roof peak: 3249 mm.
  • Other vertical measurements: 1299 mm, 762 mm, 406 mm, 200 mm, and 51 mm.

General Notes

THIS DRAWING IS A COPYRIGHT DRAWING & SHALL NOT BE REPRODUCED OR REVISED WITHOUT WRITTEN PERMISSION FROM LEIF GUSTAVSON. THIS DRAWING SHALL NOT BE USED FOR CONSTRUCTION PURPOSES UNTILL IT HAS BEEN ISSUED FOR CONSTRUCTION BY LEIF GUSTAVSON. THE GENERAL CONTRACTOR TO CHECK & VERIFY ALL DIMENSIONS & REPORT ALL ERRORS & OMISSIONS TO LEIF GUSTAVSON. DO NOT SCALE.
