ELEVATIONS - 157 VIEW ROYAL AVE - POTTING SHED
October 21, 2025Page 181 section
Architectural elevation drawings (Sheet A2) showing the east, north, south, and west views of the proposed potting shed.
157 View Royal AvenueStudio LeafAugust 1, 2025Sheet A2
157 VIEW ROYAL AVE - POTTING SHED
ELEVATIONS
Project Address: 157 VIEW ROYAL AVE VICTORIA, BC V9B 1A6
Designed By: LEIF GUSTAVSON ARCHITECTURAL TECHNOLOGIST A.I.B.C. LG@STUDIOLEAF.CA 250 480 9439
Sheet Number: A2 Scale: 1 : 48
Issue Schedule
| # | DATE | BY | DESCRIPTION |
|---|---|---|---|
| 1 | 25/05/20 | LG | FOR CLIENT REVIEW |
| 2 | 25/06/02 | LG | FOR CLIENT REVIEW |
| 3 | 25/08/01 | LG | ISSUED FOR DP |
Drawing 1: EAST
Scale: 1 : 48 Drawing depicts a tall screened/mesh fence structure.
Drawing 2: NORTH
Scale: 1 : 48
- Notes:
- ALIGN RIDGE TO EXISTING FENCE
- TENNIS COURT
- Drawing depicts the side elevation of the potting shed featuring shingle siding and a double door.
Drawing 3: SOUTH
Scale: 1 : 48
- Notes:
- TENNIS COURT
- 203 mm base dimension
- Drawing depicts the side elevation of the potting shed with mesh screening and window openings.
Drawing 4: WEST
Scale: 1 : 48
- Notes:
- ALIGN RIDGE TO EXISTING FENCE
- OUTDOOR SHOWER HEAD
- DOWNSPOUT. TIE INTO EXISTING STORM
- Dimensions:
- Total height: 4214 mm
- Main structure height: 2159 mm
- Base height: 200 mm
- FLOOR PLAN: 0 mm
- Drawing depicts the front elevation of the potting shed with shingle siding, windows, and an outdoor shower area.
