Technical Memo Appendix 1: Coastal Flood Risk Areas map

April 23, 2024Page 241 section

Duplicate map of coastal flood risks used as a reference attachment for the technical memo.

1 CALL TO ORDER- Mayor Tobias called the meeting to order at 7:00 p.m.

TOWN OF VIEW ROYAL

Coastal Flood Risk Areas

April 2024 Scale: 1:11,000

Map segment showing the northwest region, including Thetis Lake and northern residential areas.
Map segment showing the northwest region, including Thetis Lake and northern residential areas.
Map segment showing the north-central region, highlighting the Trans-Canada Highway, Burnside Road West, and Watkiss Way.
Map segment showing the north-central region, highlighting the Trans-Canada Highway, Burnside Road West, and Watkiss Way.
Map segment showing the northeast region, including Helmcken Road, Portage Inlet, and surrounding residential parcels.
Map segment showing the northeast region, including Helmcken Road, Portage Inlet, and surrounding residential parcels.
Map segment showing the southeast region, including the Island Highway, Shoreline Drive, and the Esquimalt Nation territory.
Map segment showing the southeast region, including the Island Highway, Shoreline Drive, and the Esquimalt Nation territory.
Map segment showing the southern coastline along Esquimalt Harbour.
Map segment showing the southern coastline along Esquimalt Harbour.
Map segment showing the southwest region, including the City of Colwood border and the southern portion of the Island Highway.
Map segment showing the southwest region, including the City of Colwood border and the southern portion of the Island Highway.

Legend

  • 8.46m Tsunami Water Surface Level (Red)
  • 4.63m Flood Construction Level for 2m Sea Level Rise (Yellow)
  • SSMUH Parcels ≤ 280m^2 (Up to 3 units) (Light Blue)
  • SSMUH Parcels ≥ 281m^2 (Up to 4 units) (Pink)
  • SSMUH Parcels ≥ 281m^2, within 400m of a Prescribed Frequent Transit Stop (Up to 6 units) (Purple)

Highlands Inset

  • Scale: 0 - 0.5 - 1 Kilometers
  • Features: Pike Lake, Upper Thetis Lake

Geographic Features and Jurisdictions

  • Regional Parks: Thetis Lake Regional Park, Mill Hill Regional Park
  • Municipal Parks: View Royal Park, Helmcken Centennial Park, Portage Park
  • Water Bodies: Esquimalt Harbour, Portage Inlet
  • Neighboring Jurisdictions: City of Langford, City of Colwood, Esquimalt Nation, Township of Esquimalt, District of Saanich
  • Major Roadways: Trans-Canada Hwy, Island Hwy, Burnside Rd W, Watkiss Way, Helmcken Rd, Six Mile Rd, Atkins Rd, Old Island Hwy

Map Information

  • Flood data source: 2021 Capital Regional District Flood Inundation Mapping Project
  • Disclaimer: The boundaries shown on this map are intended to be approximate. Minor changes will be permitted without amendments to this plan.
