Landscape Plan - Eltham & Helmcken
April 15, 2025Page 3521 section
Detailed landscape design plan for the townhouse project site, specifying plantings and amenity space.
Lombard North Group (Landscape Architect)Plan P1
ELTHAM & HELMCKEN
VICTORIA, B.C.
LANDSCAPE PLAN P1
RE-ISSUED FOR DEVELOPMENT PERMIT JULY 10, 2024 ISSUED FOR DEVELOPMENT PERMIT MAY 13, 2022
| NO. | DATE | REVISION |
|---|---|---|
| 1 | FEB.02.23 | S.P. GENERAL / EXISTING TREES |
| 2 | AUG.02.23 | S.P. PILOT EXPANSION |
| 3 | SEPT.14.23 | S.P. GENERAL |
| 4 | NOV.20.23 | S.P. GENERAL |
| 5 | DEC.05.23 | S.P. TREES |
| 6 | JUNE.24.24 | S.P. UPDATED SITE PLAN DATUM |
DATE: APRIL 13, 2022 SCALE: 1 : 200
PLAN
SCALE: 1:200
The main plan shows the site layout at the corner of Eltham Road and Helmcken Road. Key features include:
- Vehicular Access: Site access from Eltham Road leading to a drive aisle and visitor street parking. A vehicle barrier gate is located at the Helmcken Road entrance.
- Buildings: Five buildings labeled BLDG 1 through BLDG 5, containing units 1 through 20.
- Amenities: Outdoor amenity space, visitor bicycle parking, and PMT area.
- Landscaping: Locations for various tree and plant species, including existing trees to be retained and existing trees to be removed.
- Average Grades:
- BLDG 4: Avg. Grade: 84.61' (25.79m)
- BLDG 3: Avg. Grade: 85.57' (26.08m)
- BLDG 2: Avg. Grade: 85.39' (26.03m)
- BLDG 1 (north): Avg. Grade: 83.61' (25.48m)
- BLDG 1 (south): Avg. Grade: 84.17' (25.66m)
- Right of Way: Indicated along the northern property line.
- Sight Lines: A 6m sight line triangle (1.2m max growth height) is noted at the site access.
LEGEND
- HIGH BRANCHING TREES: TO BE A SELECTION OF: ACER X FREEMANII 'JEFFERSRED' AUTUMN BLAZE MAPLE. SIZE: 5 CM CAL. APPROXIMATE NO. - 04
- COLUMNAR TREES: TO BE A SELECTION OF: ACER X FREEMANII 'ARMSTRONG' RED MAPLE. SIZE: 6.0 CM CAL. APPROXIMATE NO. - 05
- MULTISTEM: TO BE A SELECTION OF: STAR MAGNOLIA 'REX' SIZE: 2.7 CM POT. APPROXIMATE NO. - 02
- SHRUBS: TO BE A SELECTION OF: HYDRANGEA PANICULATA 'BOBO' (BL). SIZE: 2.7 CM POT. APPROXIMATE NO. - 277
- SMALL SHRUBS: TO BE A SELECTION OF: DWARF JAPANESE SPIRAEA 'GOLDFLAME' (BL). SIZE: 2.7 CM POT. APPROXIMATE NO. - 150
- PERENNIALS: TO BE A SELECTION OF: CORAL BELLS 'PALACE PURPLE'. SIZE: 2.7 CM POT. APPROXIMATE NO. - 80
- VINES: TO BE A SELECTION OF: BOSTON IVY. SIZE: 2.7 CM POT. APPROXIMATE NO. - 05
- GROUNDCOVERS: TO BE A SELECTION OF: KINNIKINNICK 'PANCHITO'. SIZE: 10 CM POT @ 45 CM O.C. APPROXIMATE NO. - 450
NOTES
- LANDSCAPE AREAS ARE TO BE IRRIGATED WITH A FULLY AUTOMATIC UNDERGROUND IRRIGATION SYSTEM.
- THIS DRAWING IS CONCEPTUAL ONLY AND NOT INTENDED FOR CONSTRUCTION PURPOSES.
- ALL LANDSCAPE WORK AND PLANT MATERIAL SHALL CONFORM TO THE LATEST EDITION OF THE CANADIAN LANDSCAPE STANDARD.
- REFER TO ARCHITECTURAL FOR EXTERIOR FURNITURE & LIGHTING.
- REFER TO ARBORIST REPORT & TREE RETENTION PLAN FOR MANAGEMENT OF EXISTING TREES.
ROOF AMENITY PLAN
SCALE: 1:200
Detailed breakdown of private roof amenity spaces by unit:
| Unit | Amenity Type | Area |
|---|---|---|
| UNIT001 | AMENITY - OUTDOOR | 30.19 m² |
| UNIT002 | AMENITY - OUTDOOR | 42.01 m² |
| UNIT003 | AMENITY - OUTDOOR | 50.57 m² |
| UNIT004 | AMENITY - OUTDOOR | 43.08 m² |
| UNIT005 | AMENITY - OUTDOOR | 43.44 m² |
| UNIT006 | AMENITY - OUTDOOR | 43.62 m² |
| UNIT007 | AMENITY - OUTDOOR | 38.95 m² |
| UNIT008 | AMENITY - OUTDOOR | 41.39 m² |
| UNIT009 | AMENITY - OUTDOOR | 32.06 m² |
| UNIT010 | AMENITY - OUTDOOR | 40.8 m² |
| UNIT011 | AMENITY - OUTDOOR | 41.5 m² |
| UNIT012 | AMENITY - OUTDOOR | 41.49 m² |
| UNIT013 | AMENITY - OUTDOOR | 43.02 m² |
| UNIT014 | AMENITY - OUTDOOR | 47.41 m² |
| UNIT015 | AMENITY - OUTDOOR | 47.41 m² |
| UNIT016 | AMENITY - OUTDOOR | 47.06 m² |
| UNIT017 | AMENITY - OUTDOOR | 50.37 m² |
| UNIT020 | AMENITY - OUTDOOR | 49.87 m² |
ROOF DETAIL PLAN
SCALE: 1:100
A larger scale view of the roof amenity areas for units 005 through 009, showing stairs and spatial relationships.
