Council Meeting/Documents/DEVELOPMENT PERMIT 2024-03 Presentation
Presentation

DEVELOPMENT PERMIT 2024-03 Presentation

April 15, 2025Pages 379–3865 sections

Visual presentation for Council summarizing the purpose, site plan, and requested variances for the 20-unit townhouse project.

1 CALL TO ORDER- Mayor Tobias called the meeting to order at 7:00 p.m.
Purpose: Construct 20 townhouse unitsVariance requested: Building height increase from 11.25m to 11.78mVariance requested: Manoeuvering aisle width reduction from 7.6m to 6.0m

DEVELOPMENT PERMIT 2024-03

294, 296 Eltham Road and 242 Helmcken Road

Aerial photograph showing the subject properties at 294, 296 Eltham Road and 242 Helmcken Road highlighted in blue
Aerial photograph showing the subject properties at 294, 296 Eltham Road and 242 Helmcken Road highlighted in blue

PURPOSE

To consider an application for a form and character development permit with variances to construct 20 townhouse units

Page 379–386

Site Plan

Aerial site plan overlay of the proposed 20-unit townhouse development
Aerial site plan overlay of the proposed 20-unit townhouse development
Page 379–386

Elevations

West elevation (Helmcken Road)

Architectural drawing of the west elevation facing Helmcken Road
Architectural drawing of the west elevation facing Helmcken Road

Partial south elevation (Eltham Road)

Architectural drawing of the partial south elevation facing Eltham Road
Architectural drawing of the partial south elevation facing Eltham Road
Color architectural rendering showing the perspective view of the townhouse units
Color architectural rendering showing the perspective view of the townhouse units
Page 379–386

Variance for Building Height

Requested Variances

Site diagram showing individual building height requests: Building 1 (11.17 m), Building 2 (11.27 m), Building 3 (11.78 m), Building 4 (11.57 m), and Building 5 (11.10 m)
Site diagram showing individual building height requests: Building 1 (11.17 m), Building 2 (11.27 m), Building 3 (11.78 m), Building 4 (11.57 m), and Building 5 (11.10 m)
Building Height Measurement
Required 11.25m
Proposed 11.78m
Elevation drawing showing the proposed grade versus existing grade for Buildings 4 and 5
Elevation drawing showing the proposed grade versus existing grade for Buildings 4 and 5
Detailed site plan illustrating building footprints, unit numbers, and the central drive aisle
Detailed site plan illustrating building footprints, unit numbers, and the central drive aisle
Manoeuvering Aisle Measurement
Required 7.6m
Proposed 6.0m
Black and white site plan with a yellow circle highlighting the location for the arched trellis variance
Black and white site plan with a yellow circle highlighting the location for the arched trellis variance
Elevation drawing with a yellow circle highlighting the proposed arched trellis and the variance required
Elevation drawing with a yellow circle highlighting the proposed arched trellis and the variance required
Page 379–386

RECOMMENDATION:

THAT Council authorize the issuance of Development Permit with Variances Application No. 2024-03 for 294, 296 Eltham Road and 242 Helmcken Road, in accordance with plans submitted to the Development Services Department on November 12, 2024, subject to:

a. Proposed development meeting all of Town’s Zoning Bylaw requirements, except for the following variances: i. increase the building height from 11.25m to 11.75m ii. reduce the width of a manoeuvring aisle from 7.6m to 6.0m iii. siting of an accessory structure (arched trellis) in the flanking yard.

THAT Council authorize the issuance of Development Permit with Variances Application No. 2024-03 for 294, 296 Eltham Road and 242 Helmcken Road

a. Site lighting shall be dark skies friendly b. Landscape plant selection, installation, maintenance and irrigation shall meet the BC Landscape Standard

Page 379–386
