ATTACHMENTS: Sample Photos - 12 Vickery Rd

April 15, 2025Pages 658–6591 section

Photographic evidence showing water-damaged plywood, unblocked shear wall edges, and improper basement post assemblies at 12 Vickery Road.

1 CALL TO ORDER- Mayor Tobias called the meeting to order at 7:00 p.m.
12 Vickery RdWater-damaged plywoodAugmented basement posts
Underside view of wooden floor joists and plywood subfloor with extensive dark staining.
Underside view of wooden floor joists and plywood subfloor with extensive dark staining.
**Water-damaged plywood?**
Close-up of a metal strap bolted to wooden framing.
Close-up of a metal strap bolted to wooden framing.
**Strap to shear wall?**
Ceiling joists and a wall with pink fiberglass insulation.
Ceiling joists and a wall with pink fiberglass insulation.
**Unusual top plate assembly**
A square metal structural post resting on a raised concrete footing on a basement floor.
A square metal structural post resting on a raised concrete footing on a basement floor.
**“Augmented” basement posts of concern**
Wooden beams resting on a post with some orange-painted beams.
Wooden beams resting on a post with some orange-painted beams.
**Probably insufficient bearing length & no hangers**

Shear wall (?) ply edges unblocked

Cantilevered (?) deck? Poor beam pocket detail
