Council Meeting/Documents/Attachment 3 Page 1 of 3 - Site Plan 400 Nursery Hill Rd.
Appendix

Attachment 3 Page 1 of 3 - Site Plan 400 Nursery Hill Rd.

September 1, 2015Page 271 section

Hand-drawn and annotated site plan showing the existing house, deck, and proposed deck expansion near a Garry Oak tree.

400 Nursery Hill Rd.Proposed deck expansionGarry Oak tree location noted

Site Plan: 400 Nursery Hill Rd. View Royal

Scale: 1:125

Legend

  • Grey dot = Grey gate 1.5 m in diameter
  • Squiggly circle = planted trees
  • Jagged line = existing hedge
  • Ladder icon = stairs

Notes

  • Care will be taken to avoid root damage during excavation of pads.
Detailed site plan for 400 Nursery Hill Rd. showing building footprint "Under Construction," existing shed, existing patio, proposed deck extension, and easement details with various survey measurements.
Detailed site plan for 400 Nursery Hill Rd. showing building footprint "Under Construction," existing shed, existing patio, proposed deck extension, and easement details with various survey measurements.

Plan Details

  • Property Address: 400 Nursery Hill Rd. View Royal
  • Building Status: Under Construction
  • Proposed Deck Dimensions: 6.400, 4 m
  • Existing Shed Dimensions: 8.6, 4.88 m
  • Deck and Patio Measurements:
    • Deck length: 9.42, 5.03 m
    • Deck facets: 1.23, 2.13, 1.85, 1.53, 0.31
    • Existing patio: 2.23, 1.74, 2.42
  • Building Footprint and Boundary Measurements:
    • 32.908, 12.21
    • 3.35, 3.34, 0.61, 3.35
    • 2.14, 0.30, 4.28
    • 11.201
  • Easement Information:
    • Easement: FA115416
    • Plan: VIP81552
    • Measurements: 4.58, 0.61, 3.97, 1.83, 4.47, 24.342, 7.78, 6.93
Page 27
