Council Meeting/Documents/Attachment 3 Page 3 of 3 - Annotated Photo of Deck Elevation
Appendix

Attachment 3 Page 3 of 3 - Annotated Photo of Deck Elevation

September 1, 2015Page 291 section

A photograph of the existing deck and grade with annotations showing the proposed construction and safety rail requirements.

Notes 'existing dangerous drop off for toddlers'42 inch rail proposed
Architectural sketch overlaid on a photograph of a house and yard showing deck construction details and specifications for a new deck structure.
Architectural sketch overlaid on a photograph of a house and yard showing deck construction details and specifications for a new deck structure.

P23

Handwritten Annotations and Specifications:

  • existing dangerous drop off for toddlers (noted in a bubble)
  • 42" rail
  • 5/4 P.T. decking
  • 2x8 PT Joists 16 o/c
  • 6x6 Pressure Treated Beam
  • 6x6 P.T. Post
  • 18 x 18 (dimensions for footers)
  • + 4' 6" (total height measurement from ground level to top of railing)
Page 29
