Council Meeting/Documents/Boathouse Plan 053-1-1 - Attachment 3
Appendix

Boathouse Plan 053-1-1 - Attachment 3

September 1, 2015Page 411 section

Architectural elevations and floor plan for the boathouse structure at 333 Stewart Avenue.

T-Square Design & ConsultingJune 16, 2015333 Stewart Avenue

Architectural Drawings: 333 Stewart Avenue

Architectural plan and elevations for a boathouse, including front, side, and rear views, and a floor plan.
Architectural plan and elevations for a boathouse, including front, side, and rear views, and a floor plan.

Elevations

FRONT (WEST) ELEVATION

  • Scale: 1/4" = 1'-0"

SIDE (SOUTH) ELEVATION

  • Scale: 1/4" = 1'-0"

SIDE (NORTH) ELEVATION

  • Scale: 1/4" = 1'-0"
  • Notes: Hardi shingle, 1x4 trim

REAR (EAST) ELEVATION

  • Scale: 1/4" = 1'-0"

Plans

BOATHOUSE PLAN

  • Scale: 1/4" = 1'-0"
  • Area: 236 sq. ft. (21.9 m²)
  • Features: Water, deck, 6"x6" posts

Project Information

Field Detail
Client MR. TROY SKALADANYA
Address 333 STEWART AVENUE
Firm T-SQUARE Design & Consulting
2850 Lakehurst Drive, Victoria, BC
Contact design@tsquare.ca
250-382-2893
Date JUNE-08-15
Scale AS SHOWN
Designed By STREES
Drawn By D.L.
Drawing No. 053-1-1
Page 41
Extracted from: 2015 09 01 Council Agenda
