Appendix
Attachment 4 - Typical Cross Sections 2450-00-XS101 (Duplicate)
September 1, 2015Page 681 section
A duplicate copy of the engineering cross-sections for the Chilco Road development.
May 6, 2015
THETIS VALE PHASE 6 - TYPICAL CROSS SECTIONS
Project Information
- Project Name: Thetis Vale Phase 6
- Subject: Typical Cross Sections
- Client: Limona Construction
- Consultant: Associated Engineering
- Project No: 20132450
- Drawing Number: 2450-00-XS101
- Revision: G
- Sheet: 13
Volume Calculations
| Description | Quantity |
|---|---|
| CUT | 28,800 m³ |
| FILL | 33,500 m³ |
| Note | (EXCLUDES STRIPPING AND BULKING) |
Revisions
| NO. | DATE | ENG. | BY | SUBJECT |
|---|---|---|---|---|
| G | MAY 4, 2015 | DD | DAH | ISSUED FOR CONSTRUCTION |
| F | APR 23, 2015 | DD | DAH | ISSUED FOR FINAL APPROVAL |
| E | MAR 25, 2015 | DD | DAH | ISSUED FOR FINAL APPROVAL |
| D | JAN 13, 2015 | DD | DAH | RELEASED FOR APPROVAL |
| C | AUG 1, 2014 | DD | DAH | RE-ISSUED FOR APPROVAL |
Site Plan and Section Details
The drawing illustrates the following site components:
- Roads: Cheam Road, Townhouse East.
- Lot Layouts: Residential lots 8 through 19 and a townhouse development area.
- Green Space Allocations:
- Green Space: 0.11 ha.
- Green Space: 0.13 ha.
- Green Space: 0.07 ha.
- Green Space: 0.06 ha.
- Green Space: 0.07 ha.
- Cross Sections:
- X-SECTION 1-1: Horizontal chainage 0+000 to 0+070, elevation range 34.5m to 50.0m.
- X-SECTION 2-2: Horizontal chainage 1+000 to 1+160, elevation range 29.0m to 47.0m.
- X-SECTION 3-3: Horizontal chainage 2+000 to 2+120, elevation range 28.0m to 47.0m.
- X-SECTION 4-4: Horizontal chainage 3+000 to 3+030, elevation range 27.0m to 33.0m; Includes mortared rock wall details.
- X-SECTION 5-5: Horizontal chainage 4+000 to 4+020, elevation range 27.0m to 34.0m; Includes mortared rock wall details.
Page 68
