Drawing A1.5 - SHADOW STUDY - Eagle Creek Village
September 1, 2015Page 871 section
Initial shadow study analyzing solar impact at 10am and 2pm on June 21 and December 21.
February 4, 2013
EAGLE CREEK VILLAGE
Watkiss Way & Helmcken Road, View Royal, BC
SHADOW STUDY
- Drawing Number: A1.5
- Date: 04 Feb. 2013
- Scale: 1:1400
The document presents four shadow study scenarios for the development site bounded by Watkiss Way and Helmcken Road:
- 1. SHADOW STUDY - Jun 21 10am
- Site plan showing shadows for Phase I and Phase II developments on June 21 at 10:00 AM.
- 2. SHADOW STUDY - Dec 21 10am
- Site plan showing shadows for Phase I and Phase II developments on December 21 at 10:00 AM.
- 4. SHADOW STUDY - Jun 21 2pm
- Site plan showing shadows for Phase I and Phase II developments on June 21 at 2:00 PM.
- 5. SHADOW STUDY - Dec 21 2pm
- Site plan showing shadows for Phase I and Phase II developments on December 21 at 2:00 PM.
Each diagram identifies the following features:
- Watkiss Way
- Helmcken Road
- Phase I
- Phase II
- P81 (noted on Dec 21 10am diagram)
