Council Meeting/Documents/Drawing A1.5.1 - SHADOW STUDY - Eagle Creek Village
Appendix

Drawing A1.5.1 - SHADOW STUDY - Eagle Creek Village

September 1, 2015Page 881 section

Expanded shadow study analyzing impact at 10am, 2pm, and 4pm for dates in June, July, and August.

June 19, 2015

EAGLE CREEK VILLAGE

Watkiss Way & Helmcken Road, View Royal, BC

SHADOW STUDY

Shadow Study diagram for Jun 21 at 10am, showing Phase I and Phase II relative to Watkiss Way and Helmcken Road.
Shadow Study diagram for Jun 21 at 10am, showing Phase I and Phase II relative to Watkiss Way and Helmcken Road.
  • Drawing Scale: 1 : 1400
  • Date: 06/19/15
  • Drawing No: A1.5.1
Page 88
Extracted from: 2015 09 01 Council Agenda
