Subdivision Plan of Part of Lot 8, Section 9, Lake and Esquimalt Districts

SUBDIVISION PLAN OF THAT PART OF LOT 8, SECTION 9, LAKE AND ESQUIMALT DISTRICTS, PLAN 1073 LYING WEST OF THE EASTERLY BOUNDARY OF LOT 10, PLAN 1073 PRODUCED TO PORTAGE ROAD AS SHOWN ON PLAN DEPOSITED UNDER DD 29626I, LOT 10, SECTION 9, LAKE AND ESQUIMALT DISTRICT, PLAN 1073, EXCEPT PART IN PLAN VIP62251, LOT 11, SECTION 9, LAKE AND ESQUIMALT DISTRICT, PLAN 5783, EXCEPT THAT PART IN PLAN VIP62393, AND PART OF LOT 1, SECTION 100, ESQUIMALT DISTRICT (LYING PARTLY IN LAKE DISTRICT), PLAN 31445, EXCEPT PART IN PLANS 44696, VIP63185 AND VIP63186.

PLAN EPP_______

BCGS 92B.000

All distances are in metres and decimals thereof.
The intended plot size of this plan is 560mm in width by 432mm in height (C size) when plotted at a scale of 1:1250.
Grid bearings are derived from differential dual frequency GNSS observations to Esquimalt ACP (GCM #600411) and are referred to the central meridian of UTM Zone 10 North.
To obtain local astronomic bearings referred to the meridian through ______ apply the convergence angle of ___° ___' ___".
The UTM coordinates and estimated horizontal positional accuracy achieved are derived from differential dual frequency GNSS observations to Esquimalt ACP (GCM #600411).
This plan shows horizontal ground-level distances, unless otherwise specified. To compute grid distances, multiply ground-level distances by the average combined factor [CSF]. The average combined factor has been determined based on an ellipsoidal elevation of [___] metres.
● denotes standard iron post found
⊙ denotes non-standard post found

This plan lies within the jurisdiction of the Approving Officer for the Town of View Royal.
This plan lies within the Capital Regional District.
The field survey represented by this plan was completed on the ______ day of ____________, 2012.
- Rory C. O'Connell, BCLS
ECR# ____________

FOCUS FCS Land Services Limited Partnership 37 Cadillac Ave, Victoria, BC V8Z 1T3 PROJECT REF/DRAWING No. 010037621-SDSU01-R00
