Proposed Dock 333a Stewart Avenue Site Plan and Section

January 20, 2015Page 361 section

Detailed engineering drawing and site section for the proposed dock construction.

1 CALL TO ORDER
Scale 1:100November 13, 2014

Proposed Dock - 333a Stewart Avenue

Technical drawing showing the site plan and site section for a proposed dock at 333a Stewart Avenue, including property boundaries, existing structures, and proximity to Helacken Bay.
Technical drawing showing the site plan and site section for a proposed dock at 333a Stewart Avenue, including property boundaries, existing structures, and proximity to Helacken Bay.

Site Plan

  • Scale: 1:100
  • Lot Area: 1533 sq. metres
  • Civic Address: 333a Stewart Avenue
  • Legal Description: Lot D, Section 8, Esquimalt District, Plan VIP 81834
  • Date: November 13, 2014

Site Plan Details:

  • The property is situated between Stewart Avenue and Helacken Bay.
  • Existing Features: House, concrete patio (to be altered with deck), concrete steps (to be faced with wood), concrete walkway, concrete paths, concrete driveway with stone paving, and boulder wall with native planting.
  • Proposed Features: New wood steps, natural rockery, new wood deck, dock ramp, and floating dock extending into Helacken Bay.
  • Boundary Dimensions: 25.54, 18.65, 9.20, 12.12, 50.83, 9.31, 22.80.

Site Section

  • Scale: 1:100

Site Section Details:

  • The section shows the elevation profile from the upland area down to the water.
  • Key components shown in profile include:
    • Existing concrete path
    • Existing boulder wall planted with native plants
    • New wood deck
    • Dock ramp
    • Floating dock at the water level
Page 36
